SS 321/321H Pipe Suppliers. Seamless & Welded 321 Pipes, UNS S32100/S32109, 1.4541/1.4878 Pipes

//321/321H Stainless Steel Pipes

321/321H Stainless Steel Pipes

340.00

Request a Quote for 321/321H Stainless Steel Pipes from Metline Industries! (E: sales@metline.in)

Stainless Steel 321/321H Pipes Manufacturers & Suppliers, Seamless & Welded 321/321H Stainless Steel Pipes – Top Quality SS 321H Seamless Pipes at Best Prices, UNS S32100/S32109, 1.4541/1.4878 Seamless Pipes

  • Equivalents: UNS S32100/S32109, 1.4541/1.4878
  • Specification: ASTM A213 ASEM SA213, ASTM A 312 ASME SA 312 / ASTM A 358 ASME SA 358
  • Size: 1/2″ to 48″, Thickness: SCH 5S, 10S, 40S (STD), 80S (XS), 160, XXS
  • Products: Seamless Pipes, Welded Pipes, ERW Pipes, Electropolished Pipes, Square Pipes, Rectangular Pipes, Thick Wall Pipes, Thin Wall Pipes, Decorative Pipes, Polished Pipes, Round Pipes
  • Stainless steel pipes are available in sizes ranging from 1/2 in. to 48 in. & lengths of 20 ft.

Metline is one of the largest manufacturers of standard & custom industrial 321/321H stainless steel pipes. We manufacture welded and seamless 321H stainless steel pipes in schedule 10, 40 and 80 in 1/8″ to 24″ sizes. Our stainless steel 321H pipe processing capabilities include tapering, cutting, reaming, chamfering, grooving, machining and bending.

Due to their high corrosion resistance and top quality, our stainless steel 321 seamless and welded pipes are widely supplied to many industries, such as electricity, petroleum, natural gas, chemicals, shipbuilding, heating, papermaking, metallurgy and so on.

Specifications:

  • ASTM A312 – This specification covers seamless, straight-seam welded, and heavily cold worked welded austenitic stainless steel pipe intended for high-temperature and general corrosive service
  • ASTM A358 – This specification includes electric-fusion-welded austenitic chromium-nickel stainless steel pipe.

SS 321 Seamless Pipes, SS 321/321H Welded Pipes, SS 321H Pipes Manufacturers, SS 321H Welded Pipes Wholesalers, SS 321 Seamless Pipes Suppliers in Mumbai, SS 321 Seamless Pipes Importers

Description

Manufacturers of Stainless Steel 321/321H Pipes, SS 321 Seamless Pipes, SS 321H Welded Pipes, Polished 321/321H Pipes

Metline is a specialist manufacturer and supplier of 321/321H stainless steel pipes (UNS S32100/S32109, 1.4541/1.4878) in India, with over 200 customers throughout the world. Stainless steel 321H pipes are generally used for applications where corrosion protection is necessary. We manufacture, stock and sell stainless steel 321/321H, UNS S32100/S32109, 1.4541/1.4878 seamless and welded pipes or tubes. Metline is a supplier of full range of stainless steel 321 pipe schedules ranging from Sch 5 thru Double Extra Heavy. All our 321/321H stainless steel pipe offerings can be cut to size, threaded or polished per customer requirements. 321/321H stainless steel pipes are widely used in producing furnace components, heat exchangers, superheater and afterburner parts, compensators and expansion bellows, chemical and petrochemical piping systems.

All stock of 321/321H stainless steel pipes is produced in accordance with ASME/ASTM SA/A312 with dimensions and weights in accordance with ASME B36.19. ASME B 36.10. In addition to ASTM A312, the other most commonly requested specs for 321 stainless steel pipes are ASTM A269, ASTM A268, ASTM A249, and ASTM A213.

About 321/321H Stainless Steels

Stainless Steel 321 is a basic austenitic 18/8 steel (Grade 304) stabilised by Titanium (321) addition. SS 321 is used because they are not sensitive to intergranular corrosion after heating within the carbide precipitation range of 425-850°C. Stainless Steel 321 is the grade of choice for applications in the temperature range of up to about 900°C, combining high strength, resistance to scaling and phase stability with resistance to subsequent aqueous corrosion. SS 321H is a modification of SS 321 with a higher carbon content, to provide improved high temperature strength.

  • 321H also shows resistance against acid corrosion in a variety of environments.
  • Lower temperatures provide better resistance, but the metal is able to withstand up to a 10% acid solution
  • 321 stainless steels show very little resistance against chlorine or sulfuric solutions at any given temperature.

PREN of Various Grades of Stainless Steels

Grade Type Cr Mo N PREN
Ferritics
1.4003 10.5-12.5 NS 0.030 max 10.5-12.5
1.4016 430 16.0-18.0 NS NS 16.0-18.0
1.4113 434 16.0-18.0 0.9-1.4 NS 19.0-22.6
1.4509 441 17.5-18.5 NS NS 17.5-18.5
1.4521 444 17.0-20.0 1.8-2.5 0.030max 23.0-28.7
Austenitics
1.4301 304 17.5-19.5 NS 0.11max 17.5-20.8
1.4311 304LN 17.5-19.5 NS 0.12-0.22 19.4-23.0
1.4401/4 316/316L 16.5-18.5 2.0-2.5 0.11max 23.1-28.5
1.4435 316L (2.5% min Mo) 17.0-19.0 2.5-3.0 0.11max 25.3-30.7
1.4406 316LN 16.5-18.5 2.0-2.5 0.12-0.22 25.0-30.3
1.4539 904L 19.0-21.0 4.0-5.0 0.15max 32.2-39.9
1.4563 Sanicro 28 24.0-26.0 3.0-4.0 0.11max 35.9-43.0
1.4547 254SMO 19.5-20.5 6.0-7.0 0.18-0.25 42.2-47.6
Duplex
1.4162 Lean Duplex 21.0-22.0 0.1-0.8 0.20-0.25 24.5-28.6
1.4362 2304 22.0-24.0 0.1-0.6 0.05-0.20 23.1-29.2
1.4462 2205 21.0-23.0 2.5-3.5 0.10-0.22 30.8-38.1
1.44102 2507 24.0-26.0 3.0-4.0 0.24-0.35 > 402

Types of UNS S32100/S32109, 1.4541/1.4878, 321/321H Stainless Steel Pipes

SS 321H Seamless Pipe UNS S32100 Seamless Pipe WNR. 1.4541 Seamless Pipe
SS 321H Welded Pipe Stainless Steel 321/321H Round Pipe Stainless Steel 321/321H Square Pipe
Stainless Steel 321/321H Rectangular Pipe Fabricated 321/321H Stainless Steel Pipes SS 321 Electropolished Pipes

Equivalents of 321/321H Stainless Steel Grade

STANDARD WERKSTOFF NR. UNS JIS EN
SS 321 1.4541 S32100 SUS 321 X6CrNiTi18-10
SS 321H 1.4878 S32109 SUS 321H X12CrNiTi18-9

Chemical Composition (%) of UNS S32100/ S32109, 1.4541/1.4878, 321/321H Stainless Steel Pipes

SS 321 SS 321H
Ni 9 – 12 9 – 12
Cr 17 – 19 17 – 19
C 0.08 max 0.04 – 0.10
N 0.10 max
Fe Balance
Mn 2 max 2 max
Si 0.75 max 0.75 max
S 0.03 max 0.03 max
P 0.045 max 0.045 max
Ti 4xC min 5xC min
0.60% max 0.60% max

Mechanical Properties of UNS S32100/ S32109, 1.4541/1.4878, 321/321H Stainless Steel Pipes

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1457 °C (2650 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35%

Physical Properties of UNS S32100/ S32109, 1.4541/1.4878, 321/321H Stainless Steel Pipes

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (μm/m/°C) Thermal Conductivity (W/m.K) Specific Heat 0-100 °C (J/kg.K) Electrical Resistivity (nΩ.m)
0-100 °C 0-315 °C 0-538 °C at 100 °C at 500 °C
321 8027 193 16.6 17.2 18.6 16.1 22.2 500 720

Applications of UNS S31700/S31703, 1.4449/1.4438, 317/317L Stainless Steel Pipes

Stainless Steel 321 pipes find applications in a wide rage of products such as furnace components, superheater and afterburner parts, heat exchangers, compensators and expansion bellows, chemical and petrochemical piping systems.

Additional information

Product

Stainless Steel 321/321H Pipe, UNS S32100/S32109 Stainless Steel Pipes, 1.4541/1.4878 Stainless Steel Pipes

Product Size

OD (NB Sizes) 1/2" to 72"
Wall Thickness: SCH 5 to SCH XXS, Custom Thickness

Type

Seamless Pipes, Welded Pipes, Large Diameter Fabricated Pipes, 100% X Ray Welded Pipes

Other Material Grades

304, 304L, 316, 316L, 317/L, 321/321H, 310/310S, 347/347H, 904L, 254 SMO, Alloy 20, Duplex & Super Duplex

Buttweld Pipe Fittings

-ASME B16.9
-Size 1/2" NB to 72" NB
-Elbow (LR & SR, 180 Deg, 90 Deg., 45 Deg, 3D Bends, 5D Bends, 10D Bends, Tee (Equal & Reducing), Reducer (Concentric & Eccentric), End Caps, Dish Ends, Stubend (Long & Short)

Forged Fittings

-1/8"~4" (DN6~DN100)
-ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
-Threaded & Socket Weld Pipe Fittings in Pressure Rating 3000#, 6000# & 9000#
-Elbow 90 Degree, Elbow 45 Degree, Tee, Cross, Union, Street Elbow, Coupling, Half Coupling, Reducing Coupling, Cap, Hex Head Bushing, Hex Head Plug, Square Head Plug, Round Head Plug, Bull Plug, Boss, Outlet, Hex Nipple, Swage Nipple

Flanges

-Size: 1/2" (15 NB) to 48" (1200NB)
-Standards: ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
-Pressure Ratings: Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500, PN6, PN10, PN16, PN25, PN40, PN64 etc.
-Types of Flanges: Weld neck Flanges (WNRF), Slip-on Flanges (SORF), Blind Flanges (BLRF), Lap Joint Flanges
(SOLJ), Socket-weld Flanges (SWRF), Screwed (Threaded) Flanges, Long weld neck Flanges (LWNRF), Spectacle Blind Flanges, Spacer & Blind Flanges, Ring Type Joint Flanges (RTJ), Reducing Flanges, Raised Face (RF) Flanges, Orifice Flanges, Large Diameter Flanges, Custom Flanges, Drawing Flanges, Forged Flanges, Plate Flanges, Flat Face Flanges, etc.

Quality Assurance

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Marking

As per Manufacturing Specification, Heat Number Traceability
