Stainless Steel Flexible Hose Pipes Manufacturers & Suppliers – Top Quality SS Wire Braided Hose Pipes in India

SS Flexible Corrugated Metallic Hose Pipes & Assemblies – Specification BS 6501 / ISO 10380 – 100% Quality Tested

SS Flexible Hose Pipes from Size 1/4” TO 12” ID IN SS 304, 321, 316, 316L – 100% Leak Proof Flexible Hose Pipes

  1. SS Flexible Hose Pressure Rating
  2. SS End Fittings/Connections
  3. SS Hose Pipes Production Range
  4. SS Hose Selection Criteria
  5. SS Flexible Hose Pipe Manufacturers
  6. SS Flexible Hose Pipe Suppliers
SS Flexible Hose Pipes / Braided Hose Pipes Manufacturer, Exporter, Supplier

SS Flexible Hose Pipes / Braided Hose Pipes

Metline Industries is a leading manufacturer and supplier of stainless steel (SS) flexible hose assemblies, also known as flexible metal hose assemblies. We offer a complete range of ss flexible hose pipes from size 1/4” ID to 12” ID in SS 304, 321, 316 & 316L, manufactured in compliance with BS 6501, Part-1. Our stainless steel hose assemblies are available with a wide range of end connections, bore sizes and lengths. We can supply corrugated stainless steel hose assemblies that meets your most demanding technical specifications.

Stainless steel annular corrugated flexible hoses can be supplied with or without stainless steel wire braiding. Wire braiding can be single or double. Generally, an external layer of SS wire braid is provided on corrugated metal hoses, as an unbraided hose tends to elongate axially when pressure is applied. Some customers may even choose two or even three layers of braiding for high pressure applications. The braiding is highly flexible and follows the movement of the hose.

Stainless Steel (SS) Corrugated Flexible Hose Pipes - Construction

Stainless Steel (SS) Corrugated Flexible Hose Pipes – Construction

Stainless steel 304 wires are widely used to manufacture the braid over metal hoses. On customer requests we can also manufacture braids in other stainless steel grades such as SS 321 and SS 316L. Double braided hoses improve the pressure rating of an assembly by at least 30%.

There are two basic types of corrugated metal hoses, which are distinguished by the type of corrugation used during manufacturing: helical or annular corrugation. METLINE metal hoses are manufactured using the annular corrugation method.

SS wire braded flexible hose pipes are used in various industries to carry gases and liquids at elevated pressure or temperatures or high vacuum. A stainless steel hose pipe comprises of an inner hydroformed corrugated thin walled tube which is externally braided or unbraided as per requirements of our customers.

We specialise in the manufacture and export of stainless steel flexible hose pipes, ss wire braded hose pipes, hose assemblies, interlock hose, hydraulic & rubber hose, steel bellows, expansion joints and hydraulic hose fittings.

Stainless steel corrugated flexible hoses offer very high-pressure resistance, vacuum tightness, thermal stability and corrosion resistance.

Materials Used – SS Flexible/Braided Hose Pipes

Tube/Hose Material: 321 stainless steel, 316L stainless steel, 316 stainless steel

External Braiding Material: 304 stainless steel

Stainless Steel Flexible Hose Pipes Production & Supply Range

SS Flexible Metal Hose Pipes with Flange Fittings – Round, Suqare Flange or Custom Made Flanges

SS Flexible Metal Hose Pipes with Union Fittings – SS, MS

SS Flexible Metal Hose Pipes with Threaded Fittings – BSP, BSPT, NPT, UNUF, JIC

SS Flexible Metal Hose Pipes with Triclover Fittings – TC Ferrule, Tri Clamps, Gaskets

SS Flexible Metal Hose Pipes with Camlock & Quick Release Couplings

SS Flexible Metal Hose Pipes with Long Pipe Ends, or Bends or Reducer

BS 6501-1:2004 gives guidance on the installation of corrugated metal hose assemblies and on the selection of the method of construction, the flexibility type and the material used for the hose.

BS 6501-1:2004 is complementary to BS EN ISO 10380.

Product Corrugated Metal Hose Assemblies
Pressure Rating High, Medium, Low – Refer Table Below
Flexible Hose Design Temperature – 200°C Upto 800° C
Flexible Hose Pipes Materials Stainless Steel (SS) Corrugated, Teflon, Rubber, Copper, G.I., P.V.C, Nylon
External Braiding Stainless Steel (SS), G.I, Copper Asbestos, Cotton
SS Wire Braiding Layers 1 Layer, 2 Layer, 3 Layer
Application Media Water, Steam, Oil, Chemicals, Petrol, Exhaust, Fumes, Pneumatic, Grains
End Connections Swivel Type Flanges, Steel Pipes, Nut, Mild Steel Flanges, Stainless Steel Flanges or Special Grade Materials

End ConnectionsSS Flexible/Wire Braided Hose Pipes

METLINE also manufactures complete range of end fittings/connections made from carbon steel, mild steel, stainless steel and brass for stainless steel flexible hoses. The end connections are either TIG (argon) welded or brazed.

Technical Data, Pressure Rating for Stainless Steel Flexible Hose Pipes, SS Wire Braided Hose Pipes

SIZE SINGLE BRAID DOUBLE BRAID
Nominal Size Static  Dynamic bend radius Max. working Test pressure Burst  Static  Dynamic bend radius Max. working Test pressure Burst
bend radius pressure pressure bend radius pressure pressure
Inch mm mm mm bar bar bar mm mm bar bar bar
1/4 6 25 100 154 230 616 25 100 246 369 984
3/8 10 40 150 105 157 420 40 150 168 252 672
1/2 12 50 200 88 132 352 50 200 140 210 560
5/8 16 50 200 73 109 292 50 200 116 174 464
3/4 20 70 200 64 96 256 70 200 102 153 408
1 25 90 200 50 75 200 90 200 80 120 320
32 110 250 42 63 168 110 250 67 100 268
1 ½ 40 130 250 32 48 128 130 250 51 76 204
2 50 175 350 31 46 124 175 350 49 73 196
2 ½ 65 200 410 26 39 104 200 410 41 61 164
3 80 205 450 18 27 72 205 450 28 42 112
4 100 230 560 16 24 64 230 560 26 39 104
5 125 280 660 16 24 64 280 660 25 37 100
6 150 320 815 12 18 48 320 815 20 30 80
8 200 435 1015 10 16 40 435 1015 16 24 64
10 250 560 1220 6.5 10 26 560 1220 10.5 16 42

Notes:-

  • We can also supply the above hoses for higher pressures. The above values are indicative only, and for further details, please contact our sales or technical team.
  • For static pipe work, the bend radius can be reduced considerably.
  • For extra high pressure, extra braid can be provided.

Applications of Corrugated SS Flexible/Braided Hose Pipes

Typical applications for stainless steel  flexible/braided hose pipes include all chemical industries, iron and steel manufacturing, oil and gas industry, paper and board manufacturing and all process and liquid handling industries.

  1. Oil and Gas Refineries
  2. Power Plants
  3. Steel Plants
  4. Pulp & Paper Mills
  5. Nuclear Installations
  6. Fertilizer Industry
  7. Pharmaceutical Industry
  8. Chemical Industry
  9. Industrial Boilers

How to Select SS Flexible/Braided Hose Pipes?

The following factors need to be considered when purchasing a flexible metal hose connection

  1. Temperature
  2. Dynamic pressure-carrying capability
  3. Flexibility
  4. Chemical compatibility
  5. Optional accessories

Quality Assurance– SS Flexible/Braided Hose Pipes

At Metline Industries, all stainless steel flexible hose pipes are leak tested and are subject to strict inspection at each stage of the production process, from raw material purchasing to product dispatch. All raw material used in the manufacture of hoses, braiding and end-connections are tested to ensure compliance with international standards and customer requirements.

Testing and Inspection of SS Flexible/Braided Hose Pipes: Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, Third Party Inspection, Buyer Inspection
