SS 347 Tubes Suppliers. Top Quality UNS S34700/1.4550 Seamless & Welded Tubes

///347 Stainless Steel Tubes

347 Stainless Steel Tubes

305.00

SS 347 Seamless & Welded Tubes Manufacturers & Suppliers, UNS S34700/1.4550 Tubes

  • Equivalents: WRN. 1.4550, UNS S34700, AISI 347
  • Specification: ASTM A312, ASTM A213, ASTM A268, ASTM A269
  • Size: 6mm to 101.4 mm, Thickness: 0.5mm to 10mm
  • Products: Seamless Tubes, Welded Tubes, ERW Tubes, Electropolished Tubes, Square Tubes, Rectangular Tubes, Thick Wall Tubes, Thin Wall Tubes, Decorative Tubes, Polished Tubes, Round Tubes
  • Stainless Steel 347 Tubes are available in sizes ranging from 1/4 in. OD to 5″ OD in. & lengths of 20 ft.

Metline is a professional stainless steel 347 tube supplier and manufacturer with more than 30 years experience. Our stainless steel 347 tubes are produced in compliance with ASTM A213/A269/A268 standards. SS 347 tubes supplied by Metline have excellent OD tolerance and mechanical properties enabling us to full fill the most demanding requirements from our customers. The quality of our tubes is ensured by our strict manufacturing process and testings at various stages of production.

Specifications:

  • ASTM A 269 Standard for Seamless Welded Stainless Steel Tube – Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
  • ASTM A312 – Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
  • ASTM A268 – Standard Specification for Seamless and Welded Ferritic and Martensitic Stainless Steel Tubing for General Service
  • ASTM A213 – Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes

SS 347 Seamless Tubes, SS 347 Welded Tubes, SS 347 Tubes Manufacturers, SS 347 Welded Tubes Wholesalers, SS 347 Seamless Tubes Suppliers in Mumbai, SS 347 Seamless Tubes Importers

Description

Manufacturers & Suppliers of Stainless Steel 347 Tubes, UNS S34700/1.4550 Seamless & Welded Tubes

Metline is a specialist manufacturer and supplier of 347 stainless steel tubes with Bright Annealing (BA Tube) or Polishing (Surface Roughness Ra 0.18). We produce 347 stainless steel tubes outside diameter 6mm upto 5″, in wall thickness upto 10mm. Metline is a professional producer of both thin wall and thick wall stainless steel tubes, with exports to over 70 countries across the globe. In addition to 347 stainless steel tubes, we can also produce and supply related tube fittings such as ferrule fittings, compression fittings, and couplings and valves.

Pipes are used to transport something, and tubes to construct something; hence, tubes are defined by the outside diameter and wall thickness (for construction stability), and pipes are measured by inside diameter to allow a calculation for transportation viz., speed, volumes, etc.

Stainless Steel 347 Tubes Size and Weight Chart

Stainless Steel Tube Size and Weight
Wall Thickness in mm 0.5 0.6 0.7 0.8 1 1.2 1.6 2 2.6 3 3.2 3.6
O. D. in mm Weight in kg/m
6 0.069 0.081 0.093 0.104 0.125 0.144 0.176
10 0.119 0.141 0.163 0.184 0.225 0.264 0.336
12.7 0.153 0.182 0.21 0.238 0.293 0.345 0.444
14 0.169 0.201 0.233 0.264 0.325 0.384 0.496
15.87 0.192 0.229 0.266 0.301 0.372 0.44 0.571 0.694
19 0.231 0.276 0.32 0.364 0.45 0.534 0.696 0.85 1.066 1.2 1.264
25 0.306 0.366 0.425 0.484 0.6 0.714 0.936 1.15 1.456 1.65 1.744 1.926
25.4 0.311 0.372 0.432 0.492 0.61 0.726 0.952 1.17 1.482 1.68 1.776 1.962
31.8 0.918 1.208 1.49 1.898 2.16 2.288 2.538
38 1.104 1.456 1.8 2.301 2.625 2.784 3.096
44.5 1.299 1.716 2.125 2.724 3.113 3.304 3.681
50.8 1.968 2.44 3.133 3.585 3.808 4.248
63.5 2.476 3.075 3.959 4.538 4.824 5.391
76.1 2.98 3.705 4.778 5.483 5.832 6.525
101.6 4 4.98 6.435 7.395 7.872 8.82
114.3 4.453 5.547 7.173 8.247 8.78 9.84
127 4.955 6.175 7.989 9.188 9.785 10.98
152.4 5.96 7.429 9.62 11.07 11.792 13.231

Production & Stock Range for 347 UNS S34700/1.4550 Seamless & Welded Tubes

Product Stainless Steel 347 Tube
Origin India, Japan, Europe, US
Form Welded and Seamless
Specification ASTM A213, ASTM A268, ASTM A269, ASTM A789, ASTM A790
Type Fluid, Food, Decorative, Structural, Instrumentation
Round Tube (mm) 4.76 OD to 203.2 OD
Square (mm) 12.7 to 152.6
Rectangular (mm) 25.4 x 12.7 to 203.2 x 101.6
Grades
  • Austenitic Stainless Steel: 304/304L/304H(1.4301/1.4306/1.4948); 316/316L(1.4401/1.4404); 316Ti(1.4571); 321(1.4541); 309S (1.4833); 310S(1.4845); 317L(1.4438)321H(1.4878); 347H (1.4550);
  • Duplex Stainless Steel: S32001, S32003, S31500, 2205(1.4462); S32304,(1.4362);S31803,2507 (S32750), S32760(1.4501);S32101(1.4162);
  • Super Austenitic Stainless Steel: 904L, S30432, S31042, 6Mo (S31254, N08367)
  • Nickel Base Alloys: Alloy 20 (UNS N08020), Monel 200 (UNS 02200), Monel 400 (UNS N04400), Incoloy 800 (UNS N08800), Incoloy 800H (UNS N08810), Incoloy 800HT (UNS N08811), Incoloy 825 (UNS N08825), Inconel 600 (UNS N06600), 4J29, 4J36, GH3030, GH3039, C276 (UNS N10276)
  • Martensitic Stainless Steel: 410(1.4006), 410S(1.4000), 420(1.4021)
  • Ferritic Stainless Steel: 405(1.4002), 430(1.4016)
Wall Thickness 0.33 to 10.0mm
Fittings Ttri-clamp, Butt Welding, Flanges, Compression Fittings, Double Compression, Ferrule Fittings
Processing Cut-to-length, Polishing, Bright Annealed, 180 Grit, 240 Grit, 400 Grit
Test Certificates As per EN 10204 3.1
Other Tests As per Customer QAP, Hydro Test, Destructive & Non Destructive Tests
Packing Bundled Packing, or Wooden Box Packing

About 347 Stainless Steel Tube

347 is similar to the 321 stainless steels in that it is often used as a stabilized alternative to Type 304. In the case of 347, however, the stabilizing agent is columbium. This metal intensifies 347’s already present ability to withstand intergranular corrosion for maximum capabilities. Additionally, the columbium allows for 347 to undergo repeated heating in temperatures up to 1650° F. As a result, the metal is commonly applied to high temperature equipment, such as gaskets and expansion joints, along with rocket engine and chemical manufacturing.

In addition to its heat resistance properties, 347 also enjoys better resistance against creep and stress rupture corrosions. This is another advantage of type 304, as 347’s characteristics may be better suited for environments where stabilization is a primary concern.

Type 347 is known for being workable under all common welding techniques, along with hot and cold working. However, when being heat treated the metal must be heated up in the range of 2100 to 2250°F. This is due to 347’s inability to work harden under heat treatment. Cold reduction is the only method that will utilize the alloy’s elevated properties.

Types of 347, UNS S34700, 1.4550 Stainless Steel Seamless & Welded Tubes

SS 347 Seamless Tubes UNS S34700 Seamless Tubes WNR. 1.4550 Seamless Tubes
SS 347 Welded Tubes Stainless Steel 347 Round Tubes Stainless Steel 347 Square Tubes
Stainless Steel 347 Rectangular Tubes Fabricated 347 Stainless Steel Tubes 347 Electropolished Tubes

Equivalents of 347, S34700/1.4550 Stainless Steel Seamless & Welded  Tubes Grade

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 347 1.455 S34700 SUS 347 08Ch18N12B X6CrNiNb18-10

Chemical Composition of  347, S34700/1.4550 Stainless Steel Seamless & Welded Tubes

347
Ni 9 – 13
Cr 17 – 19
C 0.08 max
Mo 3 – 4
Fe Balance
Mn 2 max
Si 0.75 max
S 0.03 max
P 0.045 max
Co + Ta 10xC min
1.00 max

Mechanical Properties of  347, S34700/1.4550 Stainless Steel Seamless & Welded Tubes

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
347 515 205 40 92 201

Physical Properties of  347, S34700/ 1.4550 Stainless Steel Seamless & Welded Tubes

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
347 8000 193 15.9 16.2 17 14.2 18.7 500 740

Applications of UNS S34700/1.4550 & 347 Stainless Steel Seamless & Welded Tubes

  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
  • Pulp and Paper Industry

Additional information

Product

Stainless Steel 347 Tubes, UNS S34700/1.4550 Stainless Steel Seamless & Welded Tubes

Product Size

OD (NB Sizes) 1/2" to 72"
Wall Thickness: SCH 5 to SCH XXS, Custom Thickness

Type

Seamless, Welded, Coiled, Straight Lengths

Material Grades

304, 304L, 316, 316L, 317/L, 321/321H, 310/310S, 347/347H, 904L, 254 SMO, Alloy 20, Duplex & Super Duplex

Quality Assurance

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Marking

As per Manufacturing Specification, Heat Number Traceability
