ASTM A249 Welded Stainless Steel Tubes and Pipes

///ASTM A249 Stainless Steel Pipes and Tubes

ASTM A249 Stainless Steel Pipes and Tubes

280.00

ASTM A249 Stainless Steel Tubing, Welded Tube ASTM A249 Exporters in India – Buy Top Quality ASTM A249 304 304L 316 316L Stainless Steel Welded Tube for Heat Exchanger

Metline is a professional ASTM 249 stainless steel tubes and pipes supplier and manufacturer with more than 30 years experience. Our stainless steel tubes are produced in compliance with ASTM A249 standards in stainless steel TP304, TP304L, TP304H, TP309S, TP309H, TP310S, TP310H,TP316, TP316L, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, TP348, TP348H. Stainless steel tubes and pipes supplied by Metline have excellent OD tolerance and mechanical properties enabling us to full fill the most demanding requirements from our customers. The quality of our tubes is ensured by our strict manufacturing process and testings at various stages of production.

For us quality always stands first, and we would provide 100% free replacement to our customer. At the same time, we also strive to ensure that our quality for cold drawn stainless steel pipes and tubes is the best in the industry. Our continuous focus on quality, price and service has helped us win many order from India, and overseas. We welcome you to contact us for best prices for cold drawn seamless stainless steel tubes from our factory.

  • Specification: ASTM A249 covers nominal-wall-thickness welded tubes and heavily cold worked welded tubes made from the austenitic steels. ASTM A249 material shall conform to the prescribed tensile and hardness properties such as tensile strength, yield strength, elongation, and Rockwell hardness number
  • Grades: TP304H, TP309H, TP309HCb, TP310H, TP310HCb, TP316H, TP321H, TP347H, and TP348H are modifications of Grades TP304, TP309S, TP309Cb, TP310S, TP310Cb, TP316, TP321, TP347, and TP348
  • Size: 1/8” NB to 5” NB, 1/4” OD to 5” OD sizes stainless steel seamless tubes also available
  • Thickness :1mm to 13mm, SCH 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S as per ANSI B36.19/36.10

Why Choose Metline as Your Source for ASTM 249 Stainless Steel Tubes?

  • Quality Products: At Metline, our quality promise comes with a 100% replacement guarantee. All our products pass testing requirements of international manufacturing specification. All our stainless steel piping products are manufactured by ISO 9001 certified factory, and shipped with MTC according to EN 10204 3.1.
  • Best Price Guaranteed for A249 Welded Stainless Steel Tubes: When you source Metline Industries, you source everything directly from the manufacturer and stockholder! We have an average daily sale volume of around 15-20 tons of stainless steel pipes & tubes from a stock of over 600 tons. We believe in offering our customer’s high quantity discounts and work closely with them on all their project requirements. We always offer the most competitive prices for stainless steel tubes to both prospective and existing customers.
  • Fast Quotations and Delivery for A249 Stainless Steel Tubes: We understand your need for purchasing materials with short lead times. We have extensive stocks of standard size stainless steel pipes and tubes, enabling us to deliver goods on an immediate basis to all our customers in India and overseas. We have wide inventory of stainless steel seamless 304 and 316L pipes for fast delivery.
  • Quality Raw Materials: We use high quality raw materials to produce stainless steel pipes and tubes. Our raw materials are quality tested before being used in production of final product. We can also offer stage wise inspection for stainless steel pipes and tubes.
  • Standard and Non Standard Sizes for A249 304/316 Stainless Steel Tubes: We can offer stainless steel tubes and pipes in both standard and non standard sizes with shortest delivery times.
  • Complete Documentation: We provide complete product related documents to our customers before delivery of the goods.

Description

ASTM A249 Stainless Steel Pipes & Tubes Manufacturers & Exporters – Bright Annealed Stainless Steel Heat Exchanger Tubes

Metline is a one of the well-known distributor and manufacturer of ASTM A249 bright annealed stainless steel pipes and tubes. ASTM A249 stainless steel tubes offered by Metline are widely intended to be used for boilers, superheaters, heat exchangers, or condensers. All our stainless steel A249 304/316 pipe materials are furnished in the heat-treated condition in accordance with the required solution temperature and quenching method. Metline is a largest stockholder of ASTM A249 stainless steel tube in custom sizes (OD, thickness and length) as per the requirements given by our clients, and that too at an affordable and market leading prices. We are a leading manufacturer specialized in stainless steel seamless pipes, bright annealed tubes, and seamless coiled tubing in various stainless steel and nickel alloy grades.

Related Products: ASTM A249 Stainless Tubes Suppliers, ASTM A249 Tubing, ASTM A249 Tube Manufacturer in India, ASTM A249 Welded Tube, ASTM A249 Steel Tube, ASTM A249 Stainless Tubes

ASTM 249 Stainless Steel Pipes and Tubes Production, Stock & Supply Range

Product ASTM 249 Stainless Steel Tubes and Pipes
Standard Size 1/8” NB to 5” NB, 1/4” OD to 5” OD sizes stainless steel seamless tubes also available
Unit Length Up to 6 meters, custom cut lengths
Thickness (mm) 1mm to 13mm, SCH 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S as per ANSI B36.19/36.10
Surface Finish No.1 Pickled Finish, No.4 finish, BA Finish, Electropolished Pipes
Specification TP304H, TP309H, TP309HCb, TP310H, TP310HCb, TP316H, TP321H, TP347H, and TP348H are modifications of Grades TP304, TP309S, TP309Cb, TP310S, TP310Cb, TP316, TP321, TP347, and TP348
Type Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes
Applications Boilers, heat exchanger, heaters or condensers
Certification EN 10204 3.1
Testing Hydro Tested, Chemical, Mechanical Test, PMI
Inspection Third Party Inspection, Buyer Inspection
Packing Weaving Bag, Seaworthy Bundles, Wooden Case if required
Delivery Time 1-2 Days for Material in Stock, 7-30 Days for Make to Order Materials
Delivery condition Hot Finish, Cold Finish, Bright Annealed, Polished, Annealed and Pickled, Passivated, Stress Relived



ASTM A249 Welded/ERW Stainless Steel Tubes Stock Range

Size OD Nominal Wall Outside Diameter Length Wall
1/2″ (12.7) 0.065″ (1.65)/0.049″ (1.25) +/-0.005 (0.13) +1/8″ (3.18) – 0 +/-10.0%
3/4″ (19.1) 0.065″ (1.65)/0.049″ (1.25) +/-0.005 (0.13) +1/8″ (3.18) – 0 +/-10.0%
1″ (25.4) 0.065″ (1.65)/0.049″ (1.25) +/-0.005 (0.13) +1/8″ (3.18) – 0 +/-10.0%
1-1/2″ (38.1) 0.065″ (1.65)/0.049″ (1.25) +/-0.008″ (0.20) +1/8″ (3.18) – 0 +/-10.0%
2″ (50.8) 0.065″ (1.65)/0.049″ (1.25) +/-0.008″ (0.20) +1/8″ (3.18) – 0 +/-10.0%
2-1/2″ (63.5) 0.065″ (1.65) +/-0.010″ (0.25) +1/8″ (3.18) – 0 +/-10.0%
3″ (76.2) 0.065″ (1.65) +/-0.010″ (0.25) +1/8″ (3.18) – 0 +/-10.0%
4″ (101.6) 0.083″ (2.11) +/-0.015″ (0.38) +1/8″ (3.18) – 0 +/-10.0%
6″ (152.4) 0.083″ (2.11) +/-0.030″ (0.76) +1″ (25.4) – 0 +/-10.0%
6″ (152.4) 0.109″ (2.77) +/-0.030″ (0.76) +1″ (25.4) – 0 +/-10.0%
8″ (203.2) 0.109″ (2.77) +0.061″ (1.55)/-0.031″ (0.79) +1″ (25.4) – 0 +/-10.0%

ASTM A249 Specifications

ASTM A249 Specfication covers nominal-wall-thickness welded tubes and heavily cold worked welded tubes made from the austenitic steels. ASTM A249 material shall conform to the prescribed tensile and hardness properties such as tensile strength, yield strength, elongation, and Rockwell hardness number. Also, each ASTM A249 tube undergo mechanical tests such as tension test, flattening test, flange test, reverse-bend test, hardness test, and hydrostatic or nondestructive electric test. Tubing sizes and thicknesses usually furnished to this specification are 1/8 in. [3.2 mm] in inside diameter to 12 in. [304.8 mm] in outside diameter and 0.015 to 0.320 in. [0.4 to 8.1 mm], inclusive, in wall thickness. Tubing having other dimensions may be furnished, provided such tubes comply with all other requirements of this specification.

Chemical Composition of ASTM 249 Stainless Steel Welded Pipes and Tubes

UNS C Mn P S Si Cr Ni Mo
S30400 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0
S30403 0.035 2 0.045 0.03 1 18.0-20.0 8.0-13.0
S3160 0.08 2 0.045 0.03 1 16.0-18.0 11.0-14.0 2.0-3.0
S31603 0.035 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.0-3.0

Mechanical Composition of ASTM 249 Stainless Steel Tubes and Pipes

Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
º F(º C)
Asme SA249 TP304 Solution 1900 (1040) 75(515) 30(205) 35
Asme SA249 TP304L Solution 1900 (1040) 70(485) 25(170) 35
Asme SA249 TP316 Solution 1900(1040) 75(515) 30(205) 35
Asme SA249 TP316L Solution 1900(1040) 70(485) 25(170) 35



Available Stock of ASTM A249 Tube – ASTM A249 SS Welded Tubes

Asme SA249 Welded SS Tubing ASTM A249 Welded Stainless Steel Tubing
ASTM A249 SS Welded Tubes Supplier ASTM A249 Welded Cold Drawn Tubes Supplier
Asme SA249 Stainless Steel Welded Tube Dealer ASTM A249 Stainless Steel Square Tubes Supplier
Asme SA249 Stainless Steel Oval Tubes Supplier ASTM A249 Stainless Steel Hollow Tube Exporter
Asme SA249 Stainless Steel Electropolished Tubes ASTM A249 SS Rectangular Tubes Supplier
Asme SA249 Seamless SS Ornamental Tubes ASTM A249 SS Superheater Tubes Manufacturer
Asme SA249 SS Hexagonal Tubes Supplier ASTM A249 SS Round Tubes Supplier
Asme SA249 Stainless Steel Super heater Tubes ASTM A249 Stainless Steel Heat Exchnager Tubes
Asme SA249 Seamless Color Coated Tubes ASTM A249 SS Condenser Tubes Suppliers
Asme SA249 Hot Rolled SS Tubes Suppliers ASTM A249 Stainless Steel Boiler Tubes Supplier
Asme SA249 SS Welded Tubes Supplier ASTM A249 Stainless Steel Instrumentation Tubes
Asme SA249 Stainless Steel Coil Tubes Supplier ASTM A249 Type 304 Stainless Steel Tubes Supplier
Asme SA249 Stainless Steel Capillary Tubes Supplier ASTM A249 Schedule 40 SS Tubes Supplier
Asme SA249 Stainless Steel U Bend Tubes Supplier ASTM A249 Schedule 80 SS Tubes Supplier
Asme SA249 Welded Tubing Supplier ASTM A249 Schedule 10 SS Tubes Supplier
Asme SA249 Tubing Manufacturer in India ASTM A249 Sch 5 SS Tubes Supplier
INOX ASTM A249 Tubing Supplier ASTM A249 Stainless Steel Seamless Tubing
Asme SA249 SS 304 Welded Tubes Supplier ASTM A249 Welded Tube Manufacturer in India
Asme SA249 /ASME SA249 Tube Manufacturer in India ASTM A249/A249M Welded Tubing Supplier
Asme SA249 Bright Annealed Coil tube Supplier ASTM A249 High Pressure Tubes Supplier
Asme SA249 Stainless Steel Slot Round Tubes Supplier ASTM A249 Thin-Wall Stainless Steel Tube Exporter
Asme SA249 Welded Tubes Supplier ASME SA249 Stainless Steel Tubes Supplier
