Duplex Steel Pipe Suppliers. Duplex Seamless & Welded 2205 Pipes, UNS S31803/1.4462 Pipes

Duplex Pipes

340.00

Request a Quote for Duplex 2205 Stainless Steel Pipes from Metline Industries! (E: sales@metline.in)

Duplex Stainless Steel 2205 Pipe Manufacturers & Suppliers, Duplex Seamless & Welded 2205 Stainless Steel Pipes – Top Quality UNS S31803/1.4462 & 2205 Duplex Pipes at Best Prices

  • Equivalents: UNS S31803/1.4462 & 2205 Stainless Steel Pipes
  • Specification: ASTM A790, ASTM A789
  • Size: 1/2″ to 48″, Thickness: SCH 5S, 10S, 40S (STD), 80S (XS), 160, XXS
  • Products: Seamless Pipes, Welded Pipes, ERW Pipes, Electropolished Pipes, Square Pipes, Rectangular Pipes, Thick Wall Pipes, Thin Wall Pipes, Decorative Pipes, Polished Pipes, Round Pipes
  • Duplex 2205 stainless steel pipes are available in sizes ranging from 1/2 in. to 48 in. & lengths of 20 ft.

Metline is one of the largest manufacturers of standard & custom industrial Duplex stainless steel pipes. We manufacture welded and seamless Duplex 2205 stainless steel pipes in schedule 10, 40 and 80 in 1/8″ to 24″ sizes. Our stainless steel Duplex pipe processing capabilities include tapering, cutting, reaming, chamfering, grooving, machining and bending.

Due to their high corrosion resistance and top quality, our duplex stainless steel 2205 seamless and welded pipes are widely supplied to many industries, such as electricity, petroleum, natural gas, chemicals, shipbuilding, heating, papermaking, metallurgy and so on.

Specifications:

  • ASTM A790 – The specification covers seamless and straight-seam welded ferritic/austenitic duplex stainless steel pipe for general corrosive service, with particular emphasis on resistance to stress corrosion cracking.

Duplex Seamless Pipes, Duplex 2205 Welded Pipes, Duplex 2205 Pipes Manufacturers, Duplex 2205 Welded Pipes Wholesalers, Stainless Steel Duplex 2205 Seamless Pipes Suppliers in Mumbai, SS Duplex 2205 Seamless Pipes Importers

Description

Manufacturers of Duplex Stainless Steel 2205 Pipes, 2205 Seamless Pipes, SS 2205 Welded Pipes, UNS S31803 Duplex Pipes

Metline is a specialist manufacturer and supplier of Duplex 2205 pipes (UNS S31803/1.4462) in India, with over 200 customers throughout the world. Stainless steel Duplex pipes are generally used for applications where corrosion protection is necessary. We manufacture, stock and sell stainless steel 2205, UNS S31803/1.4462 seamless and welded pipes or tubes. Metline is a supplier of full range of stainless steel Duplex 2205 pipe schedules ranging from Sch 5 thru Double Extra Heavy. All our Duplex 2205 stainless steel pipe offerings can be cut to size, threaded or polished per customer requirements. Duplex stainless steel pipes are widely used in producing furnace components, heat exchangers, superheater and afterburner parts, compensators and expansion bellows, chemical and petrochemical piping systems.

All stock of Duplex stainless steel pipes (UNS S32205/S31803) is produced in accordance with ASME/ASTM SA/A790 with dimensions and weights in accordance with ASME B36.19. ASME B 36.10.

About Duplex 2205

Stainless Steel Duplex 2205 is the most widely used duplex (ferritic/austenitic) stainless steel grade. It finds applications due to both excellent corrosion resistance and high strength. Duplex 2205 is a nitrogen enhanced stainless steel that was developed to combat common corrosion problems encountered with the 300 series stainless steels.Duplex Steel 2205 is not generally suitable for use at temperatures above 300°C as it suffers from precipitation of brittle micro-constituents, nor below -50°C because of its ductile-to-brittle-transition.

Stock & Production Range for Duplex 2205, UNS S31803 Stainless Steel Pipes

Production Details
Product Duplex Stainless Steel Pipes, UNS S31803/1.4462 & 2205 Pipes
Outer Diameter Round Pipe : 6~710mm
Square Pipes : 10mm x 10mm – 400mm x 400mm
Rectangular Pipes: 10mm x 20mm -200mm x 400mm
Wall Thickness Round Pipes: 1.0 – 50.00 mm
Square Pipes:1.0mm-20mm
Rectangular Pipes: 0.6mm-20mm
Length 2m – 5.8m, 6m, 12m
Material Grades 304, 304L, 304H, 304N, 316, 316L, 316Ti, 317L, 310S, 321, 321H, 347H, S31803, S32750, 347, 330, 825, 904L
Surface Finish Annealed & Pickled, Hot Rolled No.1 Mill Finish, Polished, Mirror, Matte, 240 Grit, 400 Grit, 500 Grit for Stainless Steel Pipes
Pipe End Plain End/ Bevel End
Groove End
Ends Joint with Flange or Fittings
Threaded on Two Ends, One End with Coupling, One End with Plastic Cap
Marking As Per Client Requirements or Mill Standard
Packing OD Not Less Than 273mm: Loose Packing – Piece by Piece
OD less than 273mm – In Hexagonal Seaworthy Bundles Packed by Steel Strips
On Request Small Sizes May be Nested into Big Sizes
Production Method Seamless, Hot Rolled, Cold Drawn, Heat Treated, Impact Tested
Trade Term FOB, CFR, CIF, EXW
Payment Term T/T, LC
Delivery Time 15-45 days (based on quantity) after receiving advanced payment by T/T or LC

PREN of Various Grades of Stainless Steels

Grade Type Cr Mo N PREN
Ferritics
1.4003 10.5-12.5 NS 0.030 max 10.5-12.5
1.4016 430 16.0-18.0 NS NS 16.0-18.0
1.4113 434 16.0-18.0 0.9-1.4 NS 19.0-22.6
1.4509 441 17.5-18.5 NS NS 17.5-18.5
1.4521 444 17.0-20.0 1.8-2.5 0.030max 23.0-28.7
Austenitics
1.4301 304 17.5-19.5 NS 0.11max 17.5-20.8
1.4311 304LN 17.5-19.5 NS 0.12-0.22 19.4-23.0
1.4401/4 316/316L 16.5-18.5 2.0-2.5 0.11max 23.1-28.5
1.4435 316L (2.5% min Mo) 17.0-19.0 2.5-3.0 0.11max 25.3-30.7
1.4406 316LN 16.5-18.5 2.0-2.5 0.12-0.22 25.0-30.3
1.4539 904L 19.0-21.0 4.0-5.0 0.15max 32.2-39.9
1.4563 Sanicro 28 24.0-26.0 3.0-4.0 0.11max 35.9-43.0
1.4547 254SMO 19.5-20.5 6.0-7.0 0.18-0.25 42.2-47.6
Duplex
1.4162 Lean Duplex 21.0-22.0 0.1-0.8 0.20-0.25 24.5-28.6
1.4362 2304 22.0-24.0 0.1-0.6 0.05-0.20 23.1-29.2
1.4462 2205 21.0-23.0 2.5-3.5 0.10-0.22 30.8-38.1
1.44102 2507 24.0-26.0 3.0-4.0 0.24-0.35 > 40.2

Types of UNS S31803/1.4462 & 2205 Duplex Stainless Steel

SS Duplex 2205 Seamless Pipe UNS S31803 Seamless Pipe WNR. 1.4462 Seamless Pipe
SS Duplex 2205 Welded Pipe Stainless Steel Duplex 2205 Rounded pipe Stainless Steel Duplex 2205 Square pipe
Stainless Steel Duplex 2205 Rectangular Pipe Fabricated 2205 Duplex Stainless Steel Pipes SS Duplex 2205 Electropolished Pipes

Equivalents of 2205 Duplex Stainless Steel

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
2205 S31803 1.4462

Chemical Composition (%) of UNS S31803/1.4462 & 2205 Duplex Stainless Steel

Duplex 2205
Ni 4.5 – 6.5
Fe Balance
Cr 22 – 23
Mo 3 – 3.5
Mn 2.0 max
Si 1 max
P 0.030 max
N 0.14 – 0.2
S 0.02 max

Mechanical Properties of UNS S31803/1.4462 & 2205 Duplex Stainless Steel

Grade 2205 UR52N+
Tensile Strength (MPa) 620 770
Proof Stress 0.2% (MPa) 450 550
Elongation A5 (%) 25 25

Physical Properties of UNS S31803/1.4462 & 2205 Duplex Stainless Steel

Property 2205 UR52N+
Density (g.cm3) 7.805 7.81
Modulus of Elasticity (GPa) 200 205
Electrical Resistivity (Ω.m) 0.085×10-6 0.085×10-6
Thermal Conductivity (W/m.K) 19 at 100°C 17 at 100°C
Thermal Expansion (m/m.K) 13.7×10-6 to 100°C 13.5×10-6 to 200°C

Applications of UNS S31803/1.4462 & 2205 Duplex Stainless Steel

Duplex stainless steel is typically used in:

  • Chemical processing, transport and storage
  • Oil and gas exploration and offshore rigs
  • Oil and gas refining
  • Marine environments
  • Pollution control equipment
  • Pulp & paper manufacturing
  • Chemical process plant

Additional information

Product

Stainless Steel 347 Pipe, UNS S34700 Stainless Steel Pipes, 1.4550 Stainless Steel Pipes

Product Size

OD (NB Sizes) 1/2" to 72"
Wall Thickness: SCH 5 to SCH XXS, Custom Thickness

Type

Seamless Pipes, Welded Pipes, Large Diameter Fabricated Pipes, 100% X Ray Welded Pipes

Other Material Grades

304, 304L, 316, 316L, 317/L, 321/321H, 310/310S, 347/347H, 904L, 254 SMO, Alloy 20, Duplex & Super Duplex

Buttweld Pipe Fittings

-ASME B16.9
-Size 1/2" NB to 72" NB
-Elbow (LR & SR, 180 Deg, 90 Deg., 45 Deg, 3D Bends, 5D Bends, 10D Bends, Tee (Equal & Reducing), Reducer (Concentric & Eccentric), End Caps, Dish Ends, Stubend (Long & Short)

Forged Fittings

-1/8"~4" (DN6~DN100)
-ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
-Threaded & Socket Weld Pipe Fittings in Pressure Rating 3000#, 6000# & 9000#
-Elbow 90 Degree, Elbow 45 Degree, Tee, Cross, Union, Street Elbow, Coupling, Half Coupling, Reducing Coupling, Cap, Hex Head Bushing, Hex Head Plug, Square Head Plug, Round Head Plug, Bull Plug, Boss, Outlet, Hex Nipple, Swage Nipple

Flanges

-Size: 1/2" (15 NB) to 48" (1200NB)
-Standards: ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
-Pressure Ratings: Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500, PN6, PN10, PN16, PN25, PN40, PN64 etc.
-Types of Flanges: Weld neck Flanges (WNRF), Slip-on Flanges (SORF), Blind Flanges (BLRF), Lap Joint Flanges
(SOLJ), Socket-weld Flanges (SWRF), Screwed (Threaded) Flanges, Long weld neck Flanges (LWNRF), Spectacle Blind Flanges, Spacer & Blind Flanges, Ring Type Joint Flanges (RTJ), Reducing Flanges, Raised Face (RF) Flanges, Orifice Flanges, Large Diameter Flanges, Custom Flanges, Drawing Flanges, Forged Flanges, Plate Flanges, Flat Face Flanges, etc.

Quality Assurance

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Marking

As per Manufacturing Specification, Heat Number Traceability
