SS 316Ti Tubes Suppliers. Top Quality UNS S31635/1.4571 Seamless & Welded Tubes

///316Ti Stainless Steel Tubes

316Ti Stainless Steel Tubes

305.00

(1 customer review)

SS 316Ti Seamless & Welded Tubes Manufacturers & Suppliers, UNS S31635/1.4571 Tubes

  • Equivalents: WRN. 1.4571, UNS S31635 , AISI 316Ti
  • Specification: ASTM A312, ASTM A213, ASTM A268, ASTM A269
  • Size: 6mm to 101.4 mm, Thickness: 0.5mm to 10mm
  • Products: Seamless Tubes, Welded Tubes, ERW Tubes, Electropolished Tubes, Square Tubes, Rectangular Tubes, Thick Wall Tubes, Thin Wall Tubes, Decorative Tubes, Polished Tubes, Round Tubes
  • Stainless Steel 316Ti Tubes are available in sizes ranging from 1/4 in. OD to 5″ OD in. & lengths of 20 ft.

Metline is a professional stainless steel 316Ti tube supplier and manufacturer with more than 30 years experience. Our stainless steel 316Ti tubes are produced in compliance with ASTM A213/A269/A268 standards. SS 316Ti tubes supplied by Metline have excellent OD tolerance and mechanical properties enabling us to full fill the most demanding requirements from our customers. The quality of our tubes is ensured by our strict manufacturing process and testings at various stages of production.

Specifications:

  • ASTM A 269 Standard for Seamless Welded Stainless Steel Tube – Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
  • ASTM A312 – Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
  • ASTM A268 – Standard Specification for Seamless and Welded Ferritic and Martensitic Stainless Steel Tubing for General Service
  • ASTM A213 – Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes

SS 316Ti Seamless Tubes, SS 316Ti Welded Tubes, SS 316Ti Tubes Manufacturers, GOST 08ch17N13M2T Seamless & Welded Tubes, SS 316Ti Welded Tubes Wholesalers, SS 316Ti Seamless Tubes Suppliers in Mumbai, SS 316Ti Seamless Tubes Importers

Description

Manufacturers & Suppliers of Stainless Steel 316Ti Tubes, UNS S31635/1.4571 Seamless & Welded Tubes

Metline is a specialist manufacturer and supplier of 316Ti stainless steel tubes with Bright Annealing (BA Tube) or Polishing (Surface Roughness Ra 0.18). We produce 316Ti stainless steel tubes outside diameter 6mm upto 5″, in wall thickness upto 10mm. Metline is a professional producer of both thin wall and thick wall stainless steel tubes, with exports to over 70 countries across the globe. In addition to 316Ti stainless steel tubes, we can also produce and supply related tube fittings such as ferrule fittings, compression fittings, and couplings and valves.

Pipes are used to transport something, and tubes to construct something; hence, tubes are defined by the outside diameter and wall thickness (for construction stability), and pipes are measured by inside diameter to allow a calculation for transportation viz., speed, volumes, etc.

Stainless Steel 316Ti Tubes Size and Weight Chart

Stainless Steel Tube Size and Weight
Wall Thickness in mm 0.5 0.6 0.7 0.8 1 1.2 1.6 2 2.6 3 3.2 3.6
O. D. in mm Weight in kg/m
6 0.069 0.081 0.093 0.104 0.125 0.144 0.176
10 0.119 0.141 0.163 0.184 0.225 0.264 0.336
12.7 0.153 0.182 0.21 0.238 0.293 0.345 0.444
14 0.169 0.201 0.233 0.264 0.325 0.384 0.496
15.87 0.192 0.229 0.266 0.301 0.372 0.44 0.571 0.694
19 0.231 0.276 0.32 0.364 0.45 0.534 0.696 0.85 1.066 1.2 1.264
25 0.306 0.366 0.425 0.484 0.6 0.714 0.936 1.15 1.456 1.65 1.744 1.926
25.4 0.311 0.372 0.432 0.492 0.61 0.726 0.952 1.17 1.482 1.68 1.776 1.962
31.8 0.918 1.208 1.49 1.898 2.16 2.288 2.538
38 1.104 1.456 1.8 2.301 2.625 2.784 3.096
44.5 1.299 1.716 2.125 2.724 3.113 3.304 3.681
50.8 1.968 2.44 3.133 3.585 3.808 4.248
63.5 2.476 3.075 3.959 4.538 4.824 5.391
76.1 2.98 3.705 4.778 5.483 5.832 6.525
101.6 4 4.98 6.435 7.395 7.872 8.82
114.3 4.453 5.547 7.173 8.247 8.78 9.84
127 4.955 6.175 7.989 9.188 9.785 10.98
152.4 5.96 7.429 9.62 11.07 11.792 13.231

Production & Stock Range for 316Ti, UNS S31600/1.4571 Seamless & Welded Tubes

Product Stainless Steel 316Ti Tube
Origin India, Japan, Europe, US
Form Welded and Seamless
Specification ASTM A213, ASTM A268, ASTM A269, ASTM A789, ASTM A790
Type Fluid, Food, Decorative, Structural, Instrumentation
Round Tube (mm) 4.76 OD to 203.2 OD
Square (mm) 12.7 to 152.6
Rectangular (mm) 25.4 x 12.7 to 203.2 x 101.6
Grades
  • Austenitic Stainless Steel: 304/304L/304H(1.4301/1.4306/1.4948); 316/316L(1.4401/1.4404); 316Ti(1.4571); 321(1.4541); 309S (1.4833); 310S(1.4845); 317L(1.4438)321H(1.4878); 347H (1.4550);
  • Duplex Stainless Steel: S32001, S32003, S31500, 2205(1.4462); S32304,(1.4362);S31803,2507 (S32750), S32760(1.4501);S32101(1.4162);
  • Super Austenitic Stainless Steel: 904L, S30432, S31042, 6Mo (S31254, N08367)
  • Nickel Base Alloys: Alloy 20 (UNS N08020), Monel 200 (UNS 02200), Monel 400 (UNS N04400), Incoloy 800 (UNS N08800), Incoloy 800H (UNS N08810), Incoloy 800HT (UNS N08811), Incoloy 825 (UNS N08825), Inconel 600 (UNS N06600), 4J29, 4J36, GH3030, GH3039, C276 (UNS N10276)
  • Martensitic Stainless Steel: 410(1.4006), 410S(1.4000), 420(1.4021)
  • Ferritic Stainless Steel: 405(1.4002), 430(1.4016)
Wall Thickness 0.33 to 10.0mm
Fittings Ttri-clamp, Butt Welding, Flanges, Compression Fittings, Double Compression, Ferrule Fittings
Processing Cut-to-length, Polishing, Bright Annealed, 180 Grit, 240 Grit, 400 Grit
Test Certificates As per EN 10204 3.1
Other Tests As per Customer QAP, Hydro Test, Destructive & Non Destructive Tests
Packing Bundled Packing, or Wooden Box Packing

About 316Ti Stainless Steel Tubes

Grade 316Ti stainless steel has been traditionally specified by German engineers and users with the Werkstoff number 1.4571. This grade is essentially a standard carbon 316 type with titanium stabilisation and is similar in principle to the titanium stabilisation of the 304 (1.4301) type to produce 321 (1.4541). The addition of titanium is made to reduce the risk of intergranular corrosion (IC) following heating in the temperature range 425-815C.

Stainless Steel 316 is the standard molybdenum-bearing grade, second in importance to SS 304 amongst the austenitic stainless steels. The molybdenum gives SS 316 better overall corrosion resistant properties than Stainless Steel 304, particularly higher resistance to pitting and crevice corrosion in chloride environments. Stainless Steel 316 has excellent forming and welding characteristics. It is readily brake or roll formed into a variety of parts for applications in the industrial, architectural, and transportation fields. SS 316 also has outstanding welding characteristics. Post-weld annealing is not required when welding thin sections.

SS 316L, the low carbon version of SS 316 and is immune from sensitisation (grain boundary carbide precipitation).SS 316H, with its higher carbon content has application at elevated temperatures, same as SS 316Ti which is a Titanium stabilised grade. SS 316N is nitrogen enhanced with greater strength than SS 316.

Types of 316Ti, UNS S31635, 1.4571 Stainless Steel Seamless & Welded Tubes

SS 316Ti Seamless Tubes UNS S31635 Seamless Tubes WNR. 1.4571 Seamless Tubes
SS 316Ti Welded Tubes Stainless Steel 316Ti Round Tubes Stainless Steel 316Ti Square Tubes
Stainless Steel 316Ti Rectangular Tubes Fabricated 316Ti Stainless Steel Tubes 316Ti Electropolished Tubes

Equivalents of 316Ti, S31635/1.4571 Stainless Steel Seamless & Welded  Tubes Grade

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 316TI 1.4571 S31635 SUS 316Ti 320S31 08Ch17N13M2T Z6CNDT17‐123 X6CrNiMoTi17-12-2

Chemical Composition of  316Ti, S31635/1.4571 Stainless Steel Seamless & Welded Tubes

Element 316 316H 316N 316L 316Ti
Ni 10 – 14 10 – 14 10 – 14 10 – 14 10 – 14
Fe Balance
Cr 16 – 18 16 – 18 16 – 18 16 – 18 16 – 18
Mo 2 – 3 2 – 3 2 – 3 2 – 3 2 – 3
C 0.08 max 0.10 max 0.03 max 0.03 max 0.08 max
Si 0.75 max 0.75 max 0.75 max 0.75 max 0.75 max
Mn 2 max 2 max 2 max 2 max 2 max
P 0.045 max 0.045 max 0.045 max 0.045 max 0.045 max
S 0.030 max 0.030 max 0.030 max 0.030 max 0.030 max
N 0.1 max 0.1 max 0.1 max 0.1 max
Ti 5 X % (C + N)

Mechanical Properties of  316Ti, S31635/1.4571 Stainless Steel Seamless & Welded Tubes

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
316TI 515 205 35 75 205

Physical Properties of  316Ti, S31635/1.4571 Stainless Steel Seamless & Welded Tubes

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
316TI 8000 193 15.9 16.2 17 14.2 18.7 500 740

Applications of UNS S31635, 1.4571, 316Ti Stainless Steel Seamless & Welded Tubes

Stainless Steel 316Ti pipes find applications in a wide rage of industrial sectors such as chemical processes, oil and gas and automotive.

Additional information

Product

Stainless Steel 316Ti Tubes, UNS S31635/1.4571 Stainless Steel Seamless & Welded Tubes

Product Size

OD (NB Sizes) 1/2" to 72"
Wall Thickness: SCH 5 to SCH XXS, Custom Thickness

Type

Seamless, Welded, Coiled, Straight Lengths

Material Grades

304, 304L, 316, 316L, 317/L, 321/321H, 310/310S, 347/347H, 904L, 254 SMO, Alloy 20, Duplex & Super Duplex

Quality Assurance

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Marking

As per Manufacturing Specification, Heat Number Traceability

Export to Africa

Burundi, Comoros, Djibouti, Eritrea, Ethiopia, Kenya, Madagascar, Malawi, Mauritius, Mayotte, Mozambique, Reunion, Rwanda, Seychelles, Somalia, Tanzania, United Republic of Uganda, Zambia, Zimbabwe, Angola, Cameroon, Central African Republic, Chad, Congo (Brazzaville), Congo, Democratic Republic of the Equatorial Guinea, Gabon, Sao Tome and Principe, Algeria, Egypt, Libyan Arab Jamahiriya, Morroco, South Sudan, Sudan, Tunisia, Western Sahara, Botswana, Lesotho, Namibia, South Africa, Swaziland, Benin, Burkina Faso, Cape Verde, Cote d\\'Ivoire (Ivory Coast), Gambia, Ghana, Guinea, Guinea-Bissau, Liberia, Mali, Mauritania, Niger, Nigeria, Saint Helena, Senegal, Sierra Leone, Togo

Export to America

Anguilla, Antigua and Barbuda, Aruba, Bahamas, Barbados, Bonaire, Saint Eustatius and Saba, British Virgin Islands, Cayman Islands, Cuba, Curaçao, Dominica, Dominican Republic, Grenada, Guadeloupe, Haiti, Jamaica, Martinique, Monserrat, Puerto Rico, Saint-Barthélemy, St. Kitts and Nevis, Saint Lucia, Saint Martin, Saint Vincent and the Grenadines, Sint Maarten, Trinidad and Tobago, Turks and Caicos Islands, Virgin Islands (US), Belize, Costa Rica, El Salvador, Guatemala, Honduras, Mexico, Nicaragua, Panama, Argentina, Bolivia, Brazil, Chile, Colombia, Ecuador, Falkland Islands (Malvinas), French Guiana, Guyana, Paraguay, Peru, Suriname, Uruguay, Venezuela, Bermuda, Canada, Greenland, Saint Pierre and Miquelon, United States

Export to Asia

Afghanistan, Armenia, Azerbaijan, Bangladesh, Bhutan, Brunei Darussalam, Cambodia, China, Georgia, Hong Kong, India, Indonesia, Japan, Kazakhstan, South Korea, Kyrgyzstan, Laos, Macao, Malaysia, Maldives, Mongolia, Myanmar (ex-Burma), Nepal, Pakistan, Phillipines, Singapore, Sri Lanka (ex-Ceilan), Taiwan, Tajikistan, Thailand, Timor Leste (West), Turkmenistan, Uzbekistan, Vietnam

Export to Europe

Albania, Andorra, Belarus, Bosnia, Croatia, European Union, Faroe Islands, Gibraltar, Guerney and Alderney, Iceland, Jersey, Kosovo, Liechtenstein, Macedonia, Man, Island of Moldova, Monaco, Montenegro, Norway, Russia, San Marino, Serbia, Svalbard and Jan Mayen Islands, Switzerland, Turkey, Ukraine, Vatican City State (Holy See)

Export to European Union

Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, United Kingdom

Export to Middle East

Bahrain, Iraq, Iran, Israel, Jordan, Kuwait, Lebanon, Oman, Palestine, Qatar, Saudi Arabia, Syria, United Arab Emirates, Yemen
