SS 347 Welded Pipes Suppliers. UNS S34700/1.4550 Welded Large Pipes

///347 Stainless Steel Welded Pipes (1.4550, UNS S34700)

347 Stainless Steel Welded Pipes (1.4550, UNS S34700)

350.00

Specialist Manufacturers of 347 Welded/ERW/Large Diameter Stainless Steel Pipes in India – Largest Suppliers of Fabricated & Custom Size SS 347 Welded Pipes at Lowest Prices!

Metline is one of the biggest manufacturer and supplier of stainless steel 347 welded pipes in India, with daily sales of around 25-30 tons to customers across India and overseas. Our regular stock of products include SS 304/304L welded pipes, SS 316L welded pipes, SS 321/321H welded pipes, Duplex welded pipes, and SS 201 welded pipes in size range of 1/2″ NB to 24″. We also stock and manufacture stainless steel 347 welded pipes in OD size range from 1/4″ OD to 12″ OD in thickness upto 10mm.

Stainless steel electric resistance welded (ERW) pipe is manufactured by rolling metal and then welding it longitudinally across its length. SS ERW pipes are manufactured from Strip/Coils and can be manufactured upto 12” NB. For sizes from 6” NB to 36” NB, Metline can produce fabricated pipes, made from cut to size plates. The plates are first rolled and then 100% X-Ray welding is done. Since large diameter stainless steel 347 welded pipes cannot be made on a rolling mill, we produce such pipes by rolling cut to size plates and performing welding operations on them. All large diameter 347 welded stainless steel pipes, are produced as per ASTM A358 Class I to Class V specifications. Meanwhile, stainless steel 347 welded pipes in sizes from ½” to 12” (SCH 5, SCH 10, SCH 40) can be produced on rolling mill as per ASTM A312 specification.

Stainless steel 347 welded pipes are widely used in crude oil industry, chemical industry, petrochemical industry, construction industry, and food industry. In addition to SS 304 welded or fabricated pipes, we also manufacture and supply related fittings, bends, flanges and fasteners.

  • Equivalents: WNR. 1.4550, UNS S34700, AISI 347
  • Specification: ASTM A 312/ASME SA 312, ASTM A 358/ASME SA 358, ASTM A554, ASTM A249
  • Size: 1/2″ to 48″, Thickness: SCH 5S, 10S, 40S (STD), 80S (XS), 160, XXS
  • Products: Welded Pipes, ERW Pipes, Electropolished Pipes, Square Pipes, Rectangular Pipes, Thick Wall Pipes, Thin Wall Pipes, Decorative Pipes, Polished Pipes, Round Pipes
  • Stainless steel 347 welded pipes are available in sizes ranging from 1/2 in. to 48 in. & lengths of 20 ft.

Due to their high corrosion resistance and top quality, our stainless steel 347 welded pipes are widely supplied to many industries, such as electricity, petroleum, natural gas, chemicals, shipbuilding, heating, papermaking, metallurgy and so on.

Specifications:

  • ASTM A312 – This specification covers seamless, straight-seam welded, and heavily cold worked welded austenitic stainless steel pipe intended for high-temperature and general corrosive service
  • ASTM A358 – This specification includes electric-fusion-welded austenitic chromium-nickel stainless steel pipe.

Description

Stainless Steel 347 Welded Pipes Manufacturers, Exporters in India – UNS S34700, WNR. 1.4550 Welded Pipes

We manufacture 347 welded stainless steel pipes in schedule 10, 40 and 80 in 1/8″ to 24″ sizes. Our stainless steel 347 welded pipe processing capabilities include tapering, cutting, reaming, chamfering, grooving, machining and bending.

Metline Industries is a global manufacturer and supplier of stainless steel 347 welded pipes, stainless steel ERW pipes and large diameter stainless steel 347 welded pipes, with ex stock inventory of 600 tons. We manufacture, stock and sale ss 347 welded pipes in round, square and rectangular form with either mill finish or polished surface. Mill finish (Annealed & Pickled) stainless steel 347 welded pipes are generally used for industrial applications, where as polished ss 347 welded pipes are used for architectural and structural applications. Given our daily sales volume of 20-30 tons of stainless steel 3147 welded pipes in India, we are capable of offering our customers with the best quality at lowest prices in the industry. We sincerely welcome new and old customers to co operate with us for all their stainless steel 347 welded pipes requirements.

347 Welded/ERW/Large Diameter Stainless Steel Pipes Production, Stock & Supply Range

Product Stainless Steel 347 Welded/ERW/Fabricated Pipes & Tubes
Standard Size 1/2″ NB to 16″ NB
ERW Type 1/2″ NB to 24″ NB
Fabricated (EFW Type) 6″ NB to 100″ NB
Unit Length 6 m, 12 m, 18 m, Custom Length
Thickness (mm) 0.8mm – 30 mm
Surface Finish Anodized, Brushed, Mill Finished, Solution Annealed and Pickled, Polished Grit 120 – 600, Mirror Polished
Shape Round, Square, Rectangular
Specification ASTM A554, ASTM A312, ASTM A358 Class I to V, ASTM A249, ASTM A213, ASTM A268, ASTM A269, ASTM A789, ASTM A790
Type Welded, Fabricated, ERW (Electrical Resistance Weld), LSAW Pipes
Material Grades Austenitic Stainless Steel:
304/304L/304H(1.4301/1.4306/1.4948);
316/316L(1.4401/1.4404); 316Ti(1.4571); 321(1.4541); 309S
(1.4833); 310S(1.4845); 317L(1.4438)321H(1.4878); 347H (1.4550);
Duplex Stainless Steel: S32001, S32003, S31500, 2205(1.4462);
S32304,(1.4362);S31803,2507 (S32750),
S32760(1.4501);S32101(1.4162);
Super Austenitic Stainless Steel: 904L, S30432, S31042, 6Mo
(S31254, N08367)
Nickel Base Alloys: Alloy 20 (UNS N08020), Monel 200 (UNS
02200), Monel 400 (UNS N04400), Incoloy 800 (UNS N08800),
Incoloy 800H (UNS N08810), Incoloy 800HT (UNS N08811),
Incoloy 825 (UNS N08825), Inconel 600 (UNS N06600), 4J29,
4J36, GH3030, GH3039, C276 (UNS N10276)
Martensitic Stainless Steel: 410(1.4006), 410S(1.4000),
420(1.4021)
Ferritic Stainless Steel: 405(1.4002), 430(1.4016)
Applications Decoration, Construction, Hardware, Mechanical Structure, Chemical Equipment, Pharmaceutical Equipment, Food Processing
Certification EN 10204 3.1
Testing Hydro Tested, Chemical, Mechanical Test, PMI
Inspection Third Party Inspection, Buyer Inspection
Packing Weaving Bag, Seaworthy Bundles, Wooden Case if required
Delivery Time 1-2 Days for Material in Stock, 7-30 Days for Make to Order Materials
End Plain Ends, Bevelled Ends, Threaded Ends

About 347 Stainless Steel

347 is similar to the 321 stainless steels in that it is often used as a stabilized alternative to Type 304. In the case of 347, however, the stabilizing agent is columbium. This metal intensifies 347’s already present ability to withstand intergranular corrosion for maximum capabilities. Additionally, the columbium allows for 347 to undergo repeated heating in temperatures up to 1650° F. As a result, the metal is commonly applied to high temperature equipment, such as gaskets and expansion joints, along with rocket engine and chemical manufacturing.

In addition to its heat resistance properties, 347 also enjoys better resistance against creep and stress rupture corrosions. This is another advantage of type 304, as 347’s characteristics may be better suited for environments where stabilization is a primary concern.

Type 347 is known for being workable under all common welding techniques, along with hot and cold working. However, when being heat treated the metal must be heated up in the range of 2100 to 2250°F. This is due to 347’s inability to work harden under heat treatment. Cold reduction is the only method that will utilize the alloy’s elevated properties.



Types of 347, UNS S34700/1.4550 Stainless Steel Pipes

SS 347 Seamless Pipes UNS S34700 Seamless Pipes WRN. 1.4550 Seamless Pipes
SS 347 Welded Pipes Stainless Steel 347 Round Pipes Stainless Steel 347 Square Pipes
Stainless Steel 347 Rectangular Pipes Fabricated 347 Stainless Steel Pipes 347 Electropolished Pipes

Equivalents of 347 Stainless Steel Welded Pipes Grade

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 347 1.455 S34700 SUS 347 08Ch18N12B X6CrNiNb18-10

Chemical Composition Of 347, UNS S34700/1.4550 Stainless Steel Welded Pipes

347
Ni 9 – 13
Cr 17 – 19
C 0.08 max
Mo 3 – 4
Fe Balance
Mn 2 max
Si 0.75 max
S 0.03 max
P 0.045 max
Co + Ta 10xC min
1.00 max

Mechanical Properties Of 347, UNS S34700/1.4550 Stainless Steel Welded Pipes

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
347 515 205 40 92 201

Physical Properties Of 347, UNS S34700/1.4550 Stainless Steel Welded Pipes

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
347 8000 193 15.9 16.2 17 14.2 18.7 500 740

Applications of 347, UNS S34700/1.4550 Stainless Steel Welded Pipes

  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
  • Pulp and Paper Industry

Related Keywords: SS 347 Welded Pipe, SS 347 Welded Pipe, SS 347 ERW Pipe, SS 347 EFW Pipe, Stainless Steel 347 ERW Pipe, Stainless Steel 347 EFW Pipe, Stainless Steel 347 Welded Pipe, 347 Welded Pipe, ASTM A312 Stainless Steel 347 Welded Pipes, ASTM A358 Stainless Steel 347 Welded Pipes

Additional information

Product

Stainless Steel 347 Welded Pipes, Stainless Steel 347 Fabricated Pipes, Stainless Steel 347 ERW Pipes

Product Size

OD (NB Sizes) 1/2" to 72"
Wall Thickness: SCH 5 to SCH XXS, Custom Thickness

Type

Seamless, Welded, Coiled, Straight Lengths

Material Grades

304, 304L, 316, 316L, 317/L, 321/321H, 310/310S, 347/347H, 904L, 254 SMO, Alloy 20, Duplex & Super Duplex

Quality Assurance

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Marking

As per Manufacturing Specification, Heat Number Traceability

Export to Africa

Burundi, Comoros, Djibouti, Eritrea, Ethiopia, Kenya, Madagascar, Malawi, Mauritius, Mayotte, Mozambique, Reunion, Rwanda, Seychelles, Somalia, Tanzania, United Republic of Uganda, Zambia, Zimbabwe, Angola, Cameroon, Central African Republic, Chad, Congo (Brazzaville), Congo, Democratic Republic of the Equatorial Guinea, Gabon, Sao Tome and Principe, Algeria, Egypt, Libyan Arab Jamahiriya, Morroco, South Sudan, Sudan, Tunisia, Western Sahara, Botswana, Lesotho, Namibia, South Africa, Swaziland, Benin, Burkina Faso, Cape Verde, Cote d\'Ivoire (Ivory Coast), Gambia, Ghana, Guinea, Guinea-Bissau, Liberia, Mali, Mauritania, Niger, Nigeria, Saint Helena, Senegal, Sierra Leone, Togo

Export to America

Anguilla, Antigua and Barbuda, Aruba, Bahamas, Barbados, Bonaire, Saint Eustatius and Saba, British Virgin Islands, Cayman Islands, Cuba, Curaçao, Dominica, Dominican Republic, Grenada, Guadeloupe, Haiti, Jamaica, Martinique, Monserrat, Puerto Rico, Saint-Barthélemy, St. Kitts and Nevis, Saint Lucia, Saint Martin, Saint Vincent and the Grenadines, Sint Maarten, Trinidad and Tobago, Turks and Caicos Islands, Virgin Islands (US), Belize, Costa Rica, El Salvador, Guatemala, Honduras, Mexico, Nicaragua, Panama, Argentina, Bolivia, Brazil, Chile, Colombia, Ecuador, Falkland Islands (Malvinas), French Guiana, Guyana, Paraguay, Peru, Suriname, Uruguay, Venezuela, Bermuda, Canada, Greenland, Saint Pierre and Miquelon, United States

Export to Asia

Afghanistan, Armenia, Azerbaijan, Bangladesh, Bhutan, Brunei Darussalam, Cambodia, China, Georgia, Hong Kong, India, Indonesia, Japan, Kazakhstan, South Korea, Kyrgyzstan, Laos, Macao, Malaysia, Maldives, Mongolia, Myanmar (ex-Burma), Nepal, Pakistan, Phillipines, Singapore, Sri Lanka (ex-Ceilan), Taiwan, Tajikistan, Thailand, Timor Leste (West), Turkmenistan, Uzbekistan, Vietnam

Export to Europe

Albania, Andorra, Belarus, Bosnia, Croatia, European Union, Faroe Islands, Gibraltar, Guerney and Alderney, Iceland, Jersey, Kosovo, Liechtenstein, Macedonia, Man, Island of Moldova, Monaco, Montenegro, Norway, Russia, San Marino, Serbia, Svalbard and Jan Mayen Islands, Switzerland, Turkey, Ukraine, Vatican City State (Holy See)

Export to European Union

Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, United Kingdom

Export to Middle East

Bahrain, Iraq, Iran, Israel, Jordan, Kuwait, Lebanon, Oman, Palestine, Qatar, Saudi Arabia, Syria, United Arab Emirates, Yemen
