ASTM A312 Stainless Steel Tubes and Pipes

Home/Steel Pipes & Tubes/Stainless Steel Pipes/ASTM A312 Stainless Steel Pipes and Tubes

ASTM A312 Stainless Steel Pipes and Tubes

280.00

ASTM A312 Stainless Steel Pipes – Seamless/ERW/Welded Pipes Manufacturers in India – Buy Now!

Metline offers a wide range of ASTM A312 Pipes, which has excellent forming and welding characteristics. The austenitic structure gives ASTM A312 stainless steel pipes excellent toughness, even down to cryogenic temperatures. These ASME SA 312 stainless steel seamless and welded pipes can be used for manufacturing variety of parts and piping lines for applications in the industrial, architectural, and transportation fields.

For us quality always stands first, and we would provide 100% free replacement to our customer. At the same time, we also strive to ensure that our quality for cold drawn stainless steel pipes and tubes is the best in the industry. Our continuous focus on quality, price and service has helped us win many order from India, and overseas. We welcome you to contact us for best prices for ASTM A312 stainless steel pipes and tubes from our factory.

  • Specification: ASTM A312 specification covers seamless pipe and welded pipe for austenitic stainless steel. These high performance austenitic stainless steels have a fully austenitic microstructure in the quench annealed condition.
  • Grades: TP304, TP304L, TP304H, TP321H, TP321, TP316, TP316L, TP316Ti, TP310S, TP347, TP347H
  • Size: 1/8” to 24” (10.3mm to 610mm)
  • Thickness :1mm to 60mm (10s, 20, 40s, 40, 60, 80s, 80, 100, 120, 140, 160, XXH) with length up to 6 meters, custom cut lengths
  • Manufacturing Process: Seamless and Welded

Why Choose Metline as Your Source for ASTM 312 Stainless Steel Pipes?

  • Quality Products: At Metline, our quality promise comes with a 100% replacement guarantee. All our products pass testing requirements of international manufacturing specification. All our stainless steel piping products are manufactured by ISO 9001 certified factory, and shipped with MTC according to EN 10204 3.1.
  • Best Price Guaranteed for ASTM A312 Stainless Steel Pipes: When you source Metline Industries, you source everything directly from the manufacturer and stockholder! We have an average daily sale volume of around 15-20 tons of stainless steel pipes & tubes from a stock of over 600 tons. We believe in offering our customer’s high quantity discounts and work closely with them on all their project requirements. We always offer the most competitive prices for stainless steel tubes to both prospective and existing customers.
  • Fast Quotations and Delivery: We understand your need for purchasing materials with short lead times. We have extensive stocks of standard size stainless steel pipes and tubes, enabling us to deliver goods on an immediate basis to all our customers in India and overseas. We have wide inventory of stainless steel seamless 304 and 316L pipes for fast delivery.
  • Quality Raw Materials: We use high quality raw materials to produce stainless steel pipes and tubes. Our raw materials are quality tested before being used in production of final product. We can also offer stage wise inspection for stainless steel pipes and tubes.
  • Standard and Non Standard Sizes for ASTM A312 TP304/316 Stainless Steel Pipes: We can offer stainless steel tubes and pipes in both standard and non standard sizes with shortest delivery times.
  • Complete Documentation: We provide complete product related documents to our customers before delivery of the goods.

Description

ASTM A312 Stainless Steel 304/316L Pipes and Tubes Manufacturers & Suppliers

Metline is one of the leading stockholder and supplier of ASTM A312 stainless steel pipes and tubes. Our stock of ASTM A312 seamless tubes and welded pipes primarily consists of the austenitic grades of stainless steel including TP304, TP304L, TP304H, TP321H, TP321, TP316, TP316L, TP316Ti, TP310S, TP347, TP347H in annealed and pickled, 2B finish annealed, mill finish and polished conditions.

Our high quality steel pipes, good customers service, and in house pipes and tubes processing capabilities have made us one of the emerging suppliers of ASTM A312 stainless steel seamless pipes and ASTM A312 stainless steel welded pipes and tubes.

Related Products: ASTM A312 TP316L Stainless Steel Pipes, ASTM A312 TP316L Seamless Pipe Dealer, ASTM A312 TP316L ERW Pipes, ASTM A312 TP316L EFW Pipe,ASTM A312 TP316L SS Pipe, ASTM A312 TP316L Cold Draw Seamless Pipes, ASTM A312 TP316L Stainless Steel ERW Pipe

ASTM 312 Stainless Steel Pipes and Tubes Production, Stock & Supply Range

Product ASTM 312 Stainless Steel Pipes and Tubes (TP304, TP304L, TP304H, TP316, TP316L, TP316H, TP316Ti, TP321, TP321H, TP347H, 904L, TP310H, TP310S, TP317, TP317L)
Standard Size 1/8” to 24” (10.3mm to 610mm)
Unit Length Up to 6 meters, custom cut lengths
Wall Thickness 1mm to 60mm (10s, 20, 40s, 40, 60, 80s, 80, 100, 120, 140, 160, XXH)
Surface Finish 2B MIll Finish , No.4 finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish
Specification ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790
Type Seamless, Welded
Applications Marine Exteriors,  Chemical Processing equipment, Food Processing Equipment, Petroleum Refining, Pharmaceutical, Pulp & Paper Industries
Certification EN 10204 3.1
Testing Hydro Tested, Chemical, Mechanical Test, PMI
Inspection Third Party Inspection, Buyer Inspection
Packing Weaving Bag, Seaworthy Bundles, Wooden Case if required
Delivery Time 1-2 Days for Material in Stock, 7-30 Days for Make to Order Materials
Delivery condition AP (Annealed and Pickled), MP (Mechanical Polish), BA (Bright Annealed), EP (Electro Polished)

ASTM A312 Specifications

ASTM A312 specification covers seamless pipe and welded pipe for austenitic stainless steel. These high performance austenitic stainless steels have a fully austenitic microstructure in the quench annealed condition. These grades are sometime alloyed with nitrogen to improve strength or with sulphur to improve machinability. 904L was originally developed to withstand environments involving dilute sulphuric acid and it is one of the few stainless steels that, at temperatures up to 35°C, provides full resistance. This is mainly due to the high contents of chromium, nickel, molybdenum and nitrogen

Chemical Composition of ASTM A312 Stainless Steel Pipes and Tubes

Grade UNS Chemical Composition
Design C Mn P S Si Cr Ni Mb Ti Nb N Cu Ce B Al
TP304 S30400 0.08 2 0.045 0.03 1 18.0–20 8.0–11 . . . . . . . . . . . . . . . . . .
TP304L S30403 0.035 2 0.045 0.03 1 18.0–20 8.0–13 . . . . . . . . . . . . . . . . . .
TP304H S30409 0.04 – 0.1 2 0.045 0.03 1 18.0–20 8.0–11 . . . . . . . . . . . . . . . . . .
TP310S S31008 0.08 2 0.045 0.03 1 24.0- 26 19.0- 22 0.8 . . . . . . . . . . . . . . .
TP310H S31009 0.04 – 0.1 2 0.045 0.03 1 24.0–26 19.0–22 . . . . . . . . . . . . . . .
TP310H S31035 0.04 – 0.1 0.6 0.025 0.015 0.4 21.5–23.5 23.5–26.5 . . . . . . 0.40- 0.6 0.20- 0.3 2.5- 3.5 . . . 0.002- 0.008
TP316 S31600 0.08 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .
TP316L S31603 0.035 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .
TP316H S31609 0.04 – 0.1 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .
TP317 S31700 0.08 2 0.045 0.03 1 18.0–20 11.0–15 3.0–4 . . . . . . . . . . . . . . .
TP317L S31703 0.035 2 0.045 0.03 1 18.0–20 11.0–15 3.0–4 . . . . . . . . . . . . . . .
TP321 S32100 0.08 2 0.045 0.03 1 17.0–19 9.0–12 . . . Ti 5 × (C+N) min, 0.70 max . . . 0.1 . . . . . .
TP321H S32109 0.04 – 0.1 2 0.045 0.03 1 17.0–19 9.0–12 . . . 4(C+N) min; 0.70 max . . . 0.1 . . . . . .
TP321H S32654 0.02 2.0-4 0.03 0.005 0.5 24.0–25 21.0–23 7.0-8 . . . . . . 0.45- 0.55 0.30-0.6 . . .
TP321H S33228 0.04 – 0.08 1 0.02 0.015 0.3 26.0–28 31.0–33 . . . . . . 0.60- 1 . . . . . . 0.05 – 0.1 0.025
TP321H S34565 0.03 5.0-7 0.03 0.01 1 23.0–25 16.0–18 4.0-5 . . . 0.1 0.40- 0.6 . . . . . .
TP347 S34700 0.08 2 0.045 0.03 1 17.0–19 9.0–13 . . . . . . See Spec . . . . . . . . .
TP347H S34709 0.04 – 0.1 2 0.045 0.03 1 17.0–19 9.0–13 . . . . . . See Spec . . . . . . . . .
Alloy 20 N08020 0.07 2 0.045 0.035 1 19.0–21 32.0–38 2.0–3 . . . See Spec . . . 3.0– 4 . . . . . . . . .
Alloy 20 N08367 0.03 2 0.04 0.03 1 20.0–22 23.5–25.5 6.0–7 . . . . . . 0.18–0.25 0.75 . . . . . . . . .
Alloy 20 N08028 0.03 2.5 0.03 0.03 1 26.0–28 30.0–34 3.0–4 0.60–1.4
Alloy 20 N08029 0.02 2 0.025 0.015 0.6 26.0–28 30.0–34 4.0–5 0.6– 1.4

Mechanical Composition Of ASTM A312 Stainless Steel Tubes and Pipes

Grade UNS Tensile Strength, Min. ksi [MPa] Yield strength, min ksi [MPa] other
Designation
TP304 S30400 75 [515] 30 [205]
TP304L S30403 70 [485] 25 [170]
TP304H S30409 75 [515] 30 [205]
TP304H S30415 87 [600] 42 [290]
TP310S S31008 75 [515] 30 [205]
TP310H S31009 75 [515] 30 [205]
TP310H S31035 95 [655] 45 [310]
TP316 S31600 75 [515] 30 [205]
TP316L S31603 70 [485] 25 [170]
TP316H S31609 75 [515] 30 [205]
TP316H S31635 75 [515] 30 [205]
TP317 S31700 75 [515] 30 [205]
TP317L S31703 75 [515] 30 [205]
TP317L S31725 75 [515] 30 [205]
TP317L S31726 80 [550] 35 [240]
TP317L S31727 80 [550] 36 [245]
TP317L S31730 70 [480] 25 [175]
TP317L S32053 93 [640] 43 [295]
TP321 S32100 75 [515] 30 [205] welded & seamless
TP321 S32100 75 [515] 30 [205] t = 0.375 in.
TP321 S32100 70 [480] 25 [170] t > 0.375 in.
TP321H S32109 75 [515] 30 [205] welded & seamless
TP321H S32109 75 [515] 30 [205] t = 0.375 in.
TP321H S32109 70 [480] 25 [170] t > 0.375 in.
TP321H S32615 80 [550] 32 [320]
TP321H S32654 109 [750] 62 [430]
TP321H S33228 73 [500] 27 [185]
TP321H S34565 115 [795] 60 [415]
TP347 S34700 75 [515] 30 [205]
TP347H S34709 75 [515] 30 [205]
Alloy 20 N08020 80 [550] 35 [240]
Alloy 20 N08028 73 [500] 31 [214]
Alloy 20 N08029 73 [500] 31 [214]
Alloy 20 N08367 100 [690] 45 [310] t = 0.187 in.
Alloy 20 N08367 95 [655] 45 [310] t > 0.187 in.

ASTM A312 Specification and Grades Of Stainless Steel Tubes and Pipes

Grade Specification
Stainless 304/304L, 304/304H A/SA312
Stainless 309S A/SA312
Stainless 310S A/SA312
Stainless 316/316L, 316/316H A/SA312
Stainless 317/317L A/SA312
Stainless 321/321H A/SA312
Stainless 347/347H A/SA312



Materials Grades of Stainless Steel Pipes & Tubes, Under Various Specifications

Stainless Steel Seamless Pipe ASTM A312 TP304/L/H, 310/H, 316/L/H/Ti, 321/H, 347/H, 410, 904L
Stainless Steel Welded Pipe ASTM A312 TP304/L/H, 310/H, 316/L/H/Ti, 321/H, 347/H, 904L
Stainless Steel Seamless Tube ASTM A213 TP304/L/H, 310/H, 316/L/H/Ti, 321/H, 347/H, 904L
Stainless Steel Seamless Tube ASTM A269 TP304/L/H, 310/H, 316/L/H/Ti, 321/H, 347/H, 904L
Stainless Steel Welded Tube ASTM A249 TP304/L/H, 310/H, 316/L/H/Ti, 321/H, 347/H, 904L
Stainless Steel EFW Tube ASTM A358 CL. 1 to 5 TP304/L/H, 310/H, 316/L/H/Ti, 321/H, 347/H,
Stainless Steel Fabricated pipe welded from plates Fabricate form S.S. Plates as per ASTM A240 TP304/L/H, 310/H, 316/L/H/Ti, 321/H, 347/H, 904L with or without 10% Radiographic Welding.



Application Of ASTM A312 Stainless Steel Pipes and Tubes

Stainless Steel 304/316L pipes find applications in a wide rage of industrial sectors such as off-shore oil drilling, power generation, petrochemicals, gas processing, specialty chemicals, pharmaceuticals, pharmaceutical equipment, chemical equipment, sea water equipment, heat exchangers, condensers, pulp and paper industry
