Super Duplex 2507 Seamless & Welded Tubes Suppliers. UNS S32750/S32760/1.4410 Tubes

///Super Duplex 2507 Stainless Steel Tubes

Super Duplex 2507 Stainless Steel Tubes

305.00

SS 2507 Super Duplex Seamless & Welded Tube Manufacturers – 1.4410, UNS S32750/S32760

  • Equivalents: WNR. 1.4410, UNS S32750/S32760 AISI 2507
  • Specification: ASTM A 790 ASME SA 790
  • Size: 6mm to 101.4 mm, Thickness: 0.5mm to 10mm
  • Products: Seamless Tubes, Welded Tubes, ERW Tubes, Electropolished Tubes, Square Tubes, Rectangular Tubes, Thick Wall Tubes, Thin Wall Tubes, Decorative Tubes, Polished Tubes, Round Tubes
  • Super Duplex 2507 Stainless Steel Tubes are available in sizes ranging from 1/4 in. OD to 5″ OD in. & lengths of 20 ft.

Metline is a professional stainless steel Super Duplex 2507 tube supplier and manufacturer with more than 30 years experience. Our stainless steel Super Duplex 2507 tubes are produced in compliance with ASTM A790, ASTM A789 standards. SS Super Duplex 2507 tubes supplied by Metline have excellent OD tolerance and mechanical properties enabling us to full fill the most demanding requirements from our customers. The quality of our tubes is ensured by our strict manufacturing process and testings at various stages of production.

Specifications:

  • ASTM A790 – Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
  • ASTM A789 – Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service

SS Super Duplex 2507 Seamless Tubes, SS Super Duplex 2507 Welded Tubes, SS Super Duplex 2507 Tubes Manufacturers, SS Super Duplex 2507 Welded Tubes Wholesalers, UNS S32750/S32760/1.4410 Super Duplex 2507 Seamless & Welded Tubes, ASME/ASTM SA/A790/A789 Super Duplex Stainless Steel Seamless & Welded Tubes, SS Super Duplex 2507 Seamless & Welded Tubes Suppliers in Mumbai, SS Super Duplex 2507 Seamless & Welded Tubes Importers

Description

Manufacturers & Suppliers of Super Duplex 2507 Stainless Steel Seamless & Welded Tubes, UNS S32750/S32760- 1.4410 Tubes

Metline is a specialist manufacturer and supplier of SS 2507 Super Duplex Seamless and Welded Tubes with Bright Annealing (BA Tube) or Polishing (Surface Roughness Ra 0.18). We produce 2507 Super Duplex stainless steel tubes outside diameter 6mm upto 5″, in wall thickness upto 10mm. Metline is a professional producer of both thin wall and thick wall stainless steel tubes, with exports to over 70 countries across the globe. In addition to 2205 Super Duplex stainless steel tubes, we can also produce and supply related tube fittings such as ferrule fittings, compression fittings, and couplings and valves.

Pipes are used to transport something, and tubes to construct something; hence, tubes are defined by the outside diameter and wall thickness (for construction stability), and pipes are measured by inside diameter to allow a calculation for transportation viz., speed, volumes, etc.

2507 Super Duplex Stainless Steel Tubes Size and Weight Chart

Stainless Steel Tube Size and Weight
Wall Thickness in mm 0.5 0.6 0.7 0.8 1 1.2 1.6 2 2.6 3 3.2 3.6
O. D. in mm Weight in kg/m
6 0.069 0.081 0.093 0.104 0.125 0.144 0.176
10 0.119 0.141 0.163 0.184 0.225 0.264 0.336
12.7 0.153 0.182 0.21 0.238 0.293 0.345 0.444
14 0.169 0.201 0.233 0.264 0.325 0.384 0.496
15.87 0.192 0.229 0.266 0.301 0.372 0.44 0.571 0.694
19 0.231 0.276 0.32 0.364 0.45 0.534 0.696 0.85 1.066 1.2 1.264
25 0.306 0.366 0.425 0.484 0.6 0.714 0.936 1.15 1.456 1.65 1.744 1.926
25.4 0.311 0.372 0.432 0.492 0.61 0.726 0.952 1.17 1.482 1.68 1.776 1.962
31.8 0.918 1.208 1.49 1.898 2.16 2.288 2.538
38 1.104 1.456 1.8 2.301 2.625 2.784 3.096
44.5 1.299 1.716 2.125 2.724 3.113 3.304 3.681
50.8 1.968 2.44 3.133 3.585 3.808 4.248
63.5 2.476 3.075 3.959 4.538 4.824 5.391
76.1 2.98 3.705 4.778 5.483 5.832 6.525
101.6 4 4.98 6.435 7.395 7.872 8.82
114.3 4.453 5.547 7.173 8.247 8.78 9.84
127 4.955 6.175 7.989 9.188 9.785 10.98
152.4 5.96 7.429 9.62 11.07 11.792 13.231

Production & Stock Range for Super Duplex 2507, UNS S32750/S32760-1.4410 Seamless & Welded Tubes

Product Super Duplex Stainless Steel Seamless & Welded Tubes, UNS S32750/S32760 1.4410 & 2507 Tubes
Origin India, Japan, Europe, US
Form Welded and Seamless
Specification ASTM A213, ASTM A268, ASTM A269, ASTM A789, ASTM A790
Type Fluid, Food, Decorative, Structural, Instrumentation
Round Tube (mm) 4.76 OD to 203.2 OD
Square (mm) 12.7 to 152.6
Rectangular (mm) 25.4 x 12.7 to 203.2 x 101.6
Grades
  • Austenitic Stainless Steel: 304/304L/304H(1.4301/1.4306/1.4948); 316/316L(1.4401/1.4404); 316Ti(1.4571); 321(1.4541); 309S (1.4833); 310S(1.4845); 317L(1.4438)321H(1.4878); 347H (1.4550);
  • Duplex Stainless Steel: S32001, S32003, S31500, 2205(1.4462); S32304,(1.4362);S31803,2507 (S32750), S32760(1.4501);S32101(1.4162);
  • Super Austenitic Stainless Steel: 904L, S30432, S31042, 6Mo (S31254, N08367)
  • Nickel Base Alloys: Alloy 20 (UNS N08020), Monel 200 (UNS 02200), Monel 400 (UNS N04400), Incoloy 800 (UNS N08800), Incoloy 800H (UNS N08810), Incoloy 800HT (UNS N08811), Incoloy 825 (UNS N08825), Inconel 600 (UNS N06600), 4J29, 4J36, GH3030, GH3039, C276 (UNS N10276)
  • Martensitic Stainless Steel: 410(1.4006), 410S(1.4000), 420(1.4021)
  • Ferritic Stainless Steel: 405(1.4002), 430(1.4016)
Wall Thickness 0.33 to 10.0mm
Fittings Ttri-clamp, Butt Welding, Flanges, Compression Fittings, Double Compression, Ferrule Fittings
Processing Cut-to-length, Polishing, Bright Annealed, 180 Grit, 240 Grit, 400 Grit
Test Certificates As per EN 10204 3.1
Other Tests As per Customer QAP, Hydro Test, Destructive & Non Destructive Tests
Packing Bundled Packing, or Wooden Box Packing

About Super Duplex 2507 Tubes

Stainless Steel Super Duplex 2507 is designed for applications which demand exceptional strength and corrosion resistance. The high molybdenum, chromium and nitrogen content in Super Duplex 2507 results in excellent resistance to chloride pitting and crevice corrosion attack and the duplex structure provides Super Duplex 2507 with exceptional resistance to chloride stress corrosion cracking. Usage of Super Duplex Steel 2507 should be limited to applications below 600° F (316° C). Extended elevated temperature exposure can reduce both the toughness and corrosion resistance of Alloy 2507.

Types of Super Duplex 2507, UNS S32750/S32760/1.4410 Stainless Steel Seamless & Welded Tubes

SS Super Duplex 2507 Seamless Tubes UNS S32750/S32760 Seamless Tubes WNR. 1.4410 Seamless Tubes
SS Super Duplex 2507 Welded Tubes Stainless Steel Super Duplex 2507 Round Tubes Stainless Steel Super Duplex 2507 Square Tubes
Stainless Steel Super Duplex 2507 Rectangular Tubes Fabricated Super Duplex 2507 Stainless Steel Tubes Super Duplex 2507 Electropolished Tubes

Equivalents of Super Duplex 2507, S32750/S32760/1.4410 Stainless Steel Seamless & Welded Tubes Grade

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
2507 S32750/S32760 _ _ 1.4410 _ _ _

Chemical Composition of Super Duplex 2507, UNS S32750/S32760/1.4410 Seamless & Welded Tubes

Cr Ni Mo C N Mn
24.0-26.0 6.0-8.0 3.0-5.0 0.030 Max .24-.32 1.20 Max
Si Cu P S Fe
0.80 Max 0.50 Max 0.035 Max 0.020 Max Balance

Mechanical Propeties of Super Duplex 2507, UNS S32750/S32760/1.4410 Seamless & Welded Tubes

S32750 / S32760 Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
7.8 g/cm3 1350 °C (2460 °F) Psi – 80000,  MPa-550 Psi – 116000 , MPa – 800 15%

Physical Properties of Super Duplex 2507, UNS S32750/S32760/1.4410 Seamless & Welded Tubes

Super Dupex 2507
Density, lb/in3 0.28
Modulus of Elasticity, psi 29.0x 106
Coefficient of Thermal Expansion, 68-212˚F, /˚F 7.5 x 10-6
Thermal Conductivity, Btu/ft hr ˚F 8
Specific Heat, Btu/lb ˚F 0.12
Electrical Resistivity, Microhm-in 31.5

Applications of UNS S32750/S32760/1.4410 & 2507 Super Duplex  Stainless Steel Seamless & Welded Tubes

Super Duplex stainless steels are typically used in:

  • Desalination Equipment
  • Chemical process pressure vessels, piping and heat exchangers
  • Marine Applications
  • Flue Gas Scrubbing Equipment
  • Pulp & Paper Mill Equipment
  • Offshore Oil production/technology
  • Oil and gas industry equipment

Additional information

Product

Super Duplex 2507 Stainless Steel Tubes, UNS S32750/S32760/1.4410 Stainless Steel Seamless & Welded Tubes

Product Size

OD (NB Sizes) 1/2" to 72"
Wall Thickness: SCH 5 to SCH XXS, Custom Thickness

Type

Seamless, Welded, Coiled, Straight Lengths

Material Grades

304, 304L, 316, 316L, 317/L, 321/321H, 310/310S, 347/347H, 904L, 254 SMO, Alloy 20, Duplex & Super Duplex

Quality Assurance

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Marking

As per Manufacturing Specification, Heat Number Traceability
