PTFE/Teflon Hose Pipes with Quick Release Coupling in SS 304/316, with SS Wire Braiding

Home/PTFE Hoses/PTFE Hose with Quick Release Coupling (QRC)

PTFE Hose with Quick Release Coupling (QRC)

9,600.00

Buy High Quality PTFE Hoses with Quick Release Coupling (QRC) at Best Prices!

  • Construction of SS Braided PTFE (Teflon) Hose Pipes with Quick Release Coupling – Innercore of corrugated or smooth PTFE, externally reinforced with stainless steel wire braid (Single or Double).
  • Temperature: Constant use range from -50° C ~ +210° C, Instant use: -70° C ~ +260° C
  • Chemically Resistant (all common solvents, acids and bases) & Also Food Grade Quality
  • End Connection: Quick Release Coupling – BSP, BSPT, NPT Threaded

We are a specialist manufacturer of SS 304 Braided Flexible Teflon or PTFE Metal Hose Pipe with Quick Release Coupling as end connections. Since our inception, Metline has been a renowned name in manufacturing PTFE Hoses with Quick Release Coupling, also widely known as Teflon Hoses, for  the most demanding applications. Our stainless steel braided PTFE hose with QRC are used by customers in dairy, food processing, chemical and pharmaceutical industries.

Stainless Steel braided PTFE or Teflon hose pipes with Quick Release Coupling end connections are the general purpose product, and can be used in applications involving high temperatures and working pressures. Outside braiding of AISI 304 stainless steel wire is used, to give maximum pressure resistance and external protection to the hose assembly.

Description

Metline is a manufacturer and professional supplier of PTFE (Teflon) Hose with Quick Release Coupling (QRC) as end connections. We can offer PTFE hose with Quick Release Coupling (QRC) in a variety of configurations such as Smooth Bore or Convoluted Type, with stainless steel 304 or stainless steel 316 wire braiding. SS Braided Teflon Hose Pipes with QRC are widely suitable for regular operation between -70℃- to 200℃, as they exhibit high resistance to strong acid and alkali.

We can offer the following categories of high quality teflon hoses with Quick Release Coupling at the most competitive prices in the industry:

  • Smooth Bore PTFE Hose with Quick Release Coupling – Available in Sizes upto 1″
  • Convoluted PTFE Hose with Quick Release Coupling – Available in Sizes upto 8″.
  • PTFE Lined Hoses with Quick Release Coupling – Available in Sizes upto 8″

Key Features of PTFE Hoses with Quick Release Coupling (QRC)

  • Threaded to BSP, BSPT, NPT Standard
  • Quick Release Coupling’s can be used with both metal hoses as well as PTFE hoses
  • Stainless Steel 304, Stainless Steel 316, Brass, Copper

Pressure Rating for Smooth Bore PTFE Hose Pipes, with Stainless Steel 304/316 Wire Braid and Quick Release Coupling

  • Stainless Steel PTFE Hose SAE 100 R14
  • Temperature : -54Deg. C to + 260 Deg. C
Hose I.D.Hose O.D.Working PressureMin. Burst PressureMin. Bend Radius
(Inch)(MM)(Inch)(MM)(PSI)(BAR)(PSI)(BAR)(MM)(Inch)
¼”6.40.358.8261018010440720753
5/16”80.43112540175101607001004
3/8”9.50.4812.1239016595606601255
½”12.70.6416.2174012069604801656.6
5/8”160.7418.812708850803522008
¾”190.9123.110107040402802309.2
1”25.41.1529.287060348024030012

Pressure Rating for Corrugated or Convoluted PTFE Hose Pipes, with Stainless Steel 304/316 Wire Braid and Quick Release Coupling

HOSE SIZEExternal DiaMAX. Working PressureMinimum Burst PressureMinimum Bend Radius
I.D.MAX. MM@ 20°C KG/CM2 (BAR)@ 20°C KG/CM2 (BAR)RADIUS MM
Inchmm
1/4613.4614055018
3/8101612048020
1/2131911042025
5/816238031050
3/42027.56925665
12534.56424089
1.1/43239.460212150
1.1/23845.953190200
25059.437140250
2.1/263.5782496300
376.293.41769375
4101.5123.21041600
